PZ5032NS10BC-S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Programmable logic devices> Programmable logic> PZ5032NS10BC-S

PZ5032NS10BC-S: DescriptionEE PLD, 12.5ns, 32-Cell, CMOS, PQFP44,; CategoryProgrammable logic devices Programmable logic; File Size983KB，15 Pages; ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.); Websitehttps://www.nxp.com/

Download Datasheet Parametric Compare View All

PZ5032NS10BC-S Overview

EE PLD, 12.5ns, 32-Cell, CMOS, PQFP44,

PZ5032NS10BC-S Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Philips Semiconductors (NXP Semiconductors N.V.)
package instruction	QFP, TQFP44,.47SQ,32
Reach Compliance Code	unknown
Other features	YES
In-system programmable	YES
JESD-30 code	S-PQFP-G44
JESD-609 code	e0
JTAG BST	YES
Number of macro cells	32
Number of terminals	44
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	TQFP44,.47SQ,32
Package shape	SQUARE
Package form	FLATPACK
method of packing	TRAY
power supply	5 V
Programmable logic type	EE PLD
propagation delay	12.5 ns
Certification status	Not Qualified
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD

PZ5032NS10BC-S Preview

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

PZ5032NS10BC-S Related Products

	PZ5032NS10BC-S	PZ5032NS10A44	PZ5032NS10BC	PZ5032NS7BC	PZ5032NS7BC-S
Description	EE PLD, 12.5ns, 32-Cell, CMOS, PQFP44,	EE PLD, 12.5ns, 32-Cell, CMOS, PQCC44,	EE PLD, 12.5ns, 32-Cell, CMOS, PQFP44,	EE PLD, 9.5ns, 32-Cell, CMOS, PQFP44,	EE PLD, 9.5ns, 32-Cell, CMOS, PQFP44,
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)
package instruction	QFP, TQFP44,.47SQ,32	QCCJ, LDCC44,.7SQ	QFP, TQFP44,.47SQ,32	QFP, TQFP44,.47SQ,32	QFP, TQFP44,.47SQ,32
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
Other features	YES	YES	YES	YES	YES
In-system programmable	YES	YES	YES	YES	YES
JESD-30 code	S-PQFP-G44	S-PQCC-J44	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44
JESD-609 code	e0	e0	e0	e0	e0
JTAG BST	YES	YES	YES	YES	YES
Number of macro cells	32	32	32	32	32
Number of terminals	44	44	44	44	44
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	QCCJ	QFP	QFP	QFP
Encapsulate equivalent code	TQFP44,.47SQ,32	LDCC44,.7SQ	TQFP44,.47SQ,32	TQFP44,.47SQ,32	TQFP44,.47SQ,32
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	CHIP CARRIER	FLATPACK	FLATPACK	FLATPACK
power supply	5 V	5 V	5 V	5 V	5 V
Programmable logic type	EE PLD	EE PLD	EE PLD	EE PLD	EE PLD
propagation delay	12.5 ns	12.5 ns	12.5 ns	9.5 ns	9.5 ns
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	J BEND	GULL WING	GULL WING	GULL WING
Terminal pitch	0.8 mm	1.27 mm	0.8 mm	0.8 mm	0.8 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD
