MIL-DTL-38999 Series I Connectors
Coupling Mechanism
Shell Materials
Features
Bayonet, 1/3 Turn
Aluminum
Scoop proof
Environmentally sealed
Hermetic versions
Filter versions
Plugs with spring fingers for EMI control
Olive drab cadmium
Electroless nickel
Carbon steel, electrodeposited tin plating
Stainless steel, passivated
22, 20, 16, 12, 10, 8
9, 11, 13, 15, 17, 19, 21, 23, 25
128
AS39029
Crimp
Solder cup or eyelet
PCB tail
-65°C to +150°C - Electrodeposited tin-plated carbon steel (Class D)
-65°C to +175°C - Cadmium finish (Class B)
-65°C to +200°C - Nickel finish (Class F) and stainless steel (Class E)
500
Shell Platings
Contact Sizes
Shell Sizes
No. of Signal Contacts, Max.
Contact Type
Contact Styles
Operating Temperatures
Durability (Mating Cycles)
Standard Configurations
Plugs
Receptacles
Straight, with EMI spring fingers (M27467)
Front, wall mount (M27466)
Jam nut (M27468)
Front, box mount (M27496)
Rear, box mount (M27505)
Rear, wall mount (M27656)
Jam nut hermetic receptacle (MS27470)
Solder mount hermetic receptacle (MS27471)
TE Components . . . TE Technology . . . TE Know-how . . .
AMP | Agastat | CII | Hartman | Kilovac | Microdot | Nanonics | Polamco | Raychem | Rochester | DEUTSCH
SEACON Phoenix | L.L. Rowe | Phoenix Optix | AFP | SEACON
Get your product to market faster with a smarter, better solution.
TE DEUTSCH MIL-DTL-38999
SERIES I CONNECTORS
DEUTSCH 38999 Series I Connectors
MS27466
MIL SPEC NUMBER/SHELL STYLE
MS27466
Front, Wall Mount
Receptacle (DJT10)
MS27467
Straight Plug with
EMI Fingers (DJT16)
MS27468
Jam Nut Receptacle
(DJT14)
MS27470
Jam Nut Hermetic
Receptacle (DJT14)
MS27471
Solder Mount Hermetic
Receptacle (DJT11)
MS27496
Front, Box Mount
Receptacle (DJT13)
MS27505
Rear, Box Mount
Receptacle (DJT12)
MS27656
Rear, Wall Mount
Receptacle (DJT19)
CLASS
T
With Accessory Thread (MS27466,
MS27467, M27468, M27656)
E
Same As
T,
But Not Approved For
New Designs (E-Nut Not Included)
E
No Accessory Thread, Box Mount
(M27496, M27505)
G
Space-Grade Environment Resisting
Y
Hermetically Sealed
SHELL SIZE
9, 11, 13, 15, 17, 19, 21, 23, 25
T
25
F
35 S
D xxxx
MODIFICATIONS
L/C
Less Contacts
POLARIZING POSITIONS
N
Normal (omit from part number)
A, B, C, D
(B and C not available in shell size 9)
CONTACTS
P
500-Cycle Pin
S
500-Cycle Socket
H
1500-Cycle Pin
J
1500-Cycle Socket
A
Less Pin (with intent to use
nonstandard contacts)
B
Less Socket (with intent to use
nonstandard contacts)
Hermetic Contacts
P
Pin, Solder Cup
S
Socket, Solder Cup
X
Pin, Eyelet
Z
Socket, Eyelet
C
Pin, PC Tail
D
Socket, PC Tail
INSERT ARRANGEMENT
See Insert Arrangement Table
FINISH
B
Olive Drab Cadmium
F
Nickel
G
Space Grade
D
Carbon Steel, Electrodeposited Tin Plating
E
Stainless Steel, Passivated
DJT 1
0
F
25 - 35
S
D xxxx
GENERAL IDENTIFIER
DJT
DEUTSCH MIL-DTL-38999 Series I
COUPLING SYSTEM
1
Bayonet
SHELL STYLE
0
Front, Wall Mount Receptacle (M27466)
6
Straight Plug with EMI Fingers (M27467)
4
Jam Nut Receptacle (M27468)
4
Jam Nut Hermetic Receptacle (MS27470)
1
Solder Mount Hermetic Receptacle (MS27471)
3
Front, Box Mount Receptacle (M27496)
2
Rear, Box Mount Receptacle (M27505)
9
Rear, Wall Mount Receptacle (M27656)
CLASS
E
Olive Drab Cadmium
F
Nickel
G
Space Grade
H
Hermetic
MODIFICATIONS
6149
Less Contacts
POLARIZING POSITIONS
N
Normal
A, B, C, D
(B and C not available in shell size 9)
CONTACTS
P
500-Cycle Pin
S
500-Cycle Socket
H
1500-Cycle Pin
J
1500-Cycle Socket
A
Less Pin (with intent to use
nonstandard contacts)
B
Less Socket (with intent to use
nonstandard contacts)
Hermetic Contacts
P
Pin, Solder Cup
S
Socket, Solder Cup
X
Pin, Eyelet
Z
Socket, Eyelet
C
Pin, PC Tail
D
Socket, PC Tail
INSERT ARRANGEMENT
See Insert Arrangement Table
SHELL SIZE
09, 11, 13, 15, 17, 19, 21, 23, 25
AEROSPACE, DEFENSE & MARINE
/// DEUTSCH MIL-DTL-38999 SERIES I CONNECTORS QRG
PAGE 3
