FACTSHEET F-202-1
TCSD
TMM
6,6 mm
TCSD–20–D–02–01–N–R
2mm IDC CABLE STRIPS
TCSD SERIES
Mates with:
TMM, TMMH, STMM,
MMT, TW, MTMM, EHT
TYPE
STRIP
NO. PINS
PER ROW
END
OPTION
LENGTH
01
PLATING
OPTION
N
OTHER
OPTION
FEATURES
• Low profile, only 5mm
(.200") assembled
height
• Four-finger contacts
optimize normal,
insertion and
withdrawal forces
• Ask about our
custom IDC design
capabilities
–05, –08,
–10, –12, –13,
–15, –17, –20,
–22, –25
(Call for other sizes)
= Assembled Length
Assembled Length
in INCHES (±1/8")
2 inches minimum
–“XX.XX”
= Notch Polarization
–N
= Gold flash on contact area,
150
µ
"(3,81
µ
m) Tin on balance
Leave blank for standard plating:
30µ"(0,76µm) Gold on contact area
–F
SPECIFICATIONS
For complete specifications
see www.samtec.com?TCSD
Insulator Material:
Black Glass Filled
Polyester
Contact:
BeCu
Current Rating:
1A
Operating Temp Range:
-40°C to +105°C
Plating:
Au or Sn over 50µ"
(1,27µm) Ni
Lead Size Accepted:
(0,48mm) .019" to
(0,53mm) .021"
Contact Resistance:
10 mΩ maximum
Insertion Depth:
(2,87mm) .113" to
(3,17mm) .125"
Insertion Force:
2 oz. (0,56N) average
Withdrawal Force:
1.4 oz (0,39N) average
Wire:
28 AWG 7/36 Stranded,
Tinned, Copper with
Gray PVC Insulator
= Single End
–S
= Double End
–D
= Position Polarization
–P “XX”
–D “XX”
= Daisy Chain
2"
min.
“XX”
±
1/8"
Double
Row
Connectors
Outer
Most
(End of
assembly)
4
01
02
Specify “XX” as position
number. Same position
will be polarized on
both ends.
1
4" minimum
TCSD
= Socket Strip
(1,02)
.040
(3,17)
.125
–B “XX”
= Breakout
Specify “XX” as number of
conductors to be broken out.
= Reversed
–R
5
01
(4,00)
.158
“XX”
5"max.
2"min.
Breakout starts with Number 1
lead indicated by brown wire or
red stripe. Shown on top side.
2
= Middle Reverse
–M
POLARIZING
KEY
Specify PK-01-07 for
polarizing key.
Also polarizes SMM
Series socket strips
(5,08)
.200
No. of Positions X (2,00) .0787
+ (4,00) .157
(1,00)
.039
= Reverse Wiring
–RW
Requires –DXX
5
= Outside Reverse
01
–O
(2,00)
.0787
(2,00)
.0787
02
Note:
TCSD Series
assemblies are non-
standard, non-returnable.
Blue or black wire
opposite position #1.
Due to technical progress, all designs, specifications and components are subject to change without notice.
3
Requires –DXX
5
