Product Information
ÖLFLEX® SOLAR XLR-R
Page 1 of 3
Valid: 07.02.2012
The new generation of electron beam cross-linked solar cables with reduced diameters - TÜV type approved
Product Description
Reduced outer diameters enable space and weight saving installation;Reduction of flame propagation as well as of
toxic combustion gases in the event of fire;Robust against mechanical impacts;Colour-coding of the core insulation
simplifies the differentiation of the polarity during installation;Exact quantity control during installation by meter marking
on the cable sheath
Application range
• For the cabling between the solar modules and as an extension cable between the individual module strings or
DC/AC inverter
• Gable and flat roof photovoltaic systems
• Photovoltaic plants and solar parks
• For the cabling of flexible or building- integrated photovoltaic systems
Benefits
• Reduced outer diameters enable space and weight saving installation
• Reduction of flame propagation as well as of toxic combustion gases in the event of fire
• Robust against mechanical impacts
• Colour-coding of the core insulation simplifies the differentiation of the polarity during installation
• Exact quantity control during installation by meter marking on the cable sheath
Design
• Conductor: fine-wire tinned-copper strands
• Core insulation: electron beam cross-linked copolymer
• Colour of core insulation: white, red or blue
• Outer sheath: electron beam cross-linked copolymer
• Outer sheath colour: black
Product Information
ÖLFLEX® SOLAR XLR-R
Page 2 of 3
Valid: 07.02.2012
Approvals
• TÜV Type approved (2PfG 1169/08.07)
• Halogen-free according to EN 50267-2-1/-2
• Ozone-resistant according to EN 50396
• Weather/UV-resistant acc. to HD 605/A1
• Acid and alkali-resistant acc. EN 60811-2-1
Product features
• Excellent weather, temperature and UV-resistance
• Good notch and abrasion resistance
• Good heat pressure resistance
• Halogen-free and flame-retardant
• XLR-R = X-Linked Radiated-Reduced Proven electron beam cross-linked quality
Technical Data
Approvals
PV1-F (TÜV type approved according to 2 PfG
1169/08.2007)
Conductor stranding
Fine wire according to VDE 0295, class 5/IEC
60228 class 5
Minimum bending radius
Fixed installation: 4 x outer diameter
Nominal voltage
AC U0/U : 600/1000 V DC U0/U : 900/1500 V Max.
permissible operating voltage: DC 1,8 kV
(Conductor-conductor, non earthed system)
Test voltage
AC 6500 V
Current rating
Im compliance with TÜV requirements spec. 2 PfG
1169/08.2007 table 1
Temperature range
-40°C to +120°C max. conductor temperature based on
EN 60216-1 Ambient temperature range according to TÜV
2 PfG 1169/08.2007: -40°C to +90°C
Article List
Part
number
Conductor
cross-section (mm²)
Outer
diameter (mm)
Copper
index (kg/km)
Weight
(kg/km)
ÖLFLEX® SOLAR XLR-R Core insulation: white / Outer sheath: black
0023175
0023176
1,5
2,5
4.4
4.8
14.4
24.0
34
46
Product Information
ÖLFLEX® SOLAR XLR-R
Page 3 of 3
Valid: 07.02.2012
0023177
0023178
0023179
0023180
4
6
10
16
5.2
5.8
7.0
8.3
38.4
57.6
96.0
153.6
63
86
132
197
Core insulation: red / Outer sheath: black
0023186
0023187
0023188
0023189
0023190
0023191
1,5
2,5
4
6
10
16
4.4
4.8
5.2
5.8
7.0
8.3
24.0
38.4
57.6
96.0
153.6
34
46
63
86
132
197
Core insulation: blue / Outer sheath: black
0023192
0023193
0023194
0023195
0023196
0023197
Footnote:
Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available
upon request.
Copper price basis: EUR 150/100kg. Refer to Appendix T17 for the definition and calculation of copper-related surcharges.
Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
Packaging size: Coil 100 m; Drum (500; 1000) m
Photographs are not to scale and do not represent detailed images of the respective products.
1,5
2,5
4
6
10
16
4.4
4.8
5.2
5.8
7.0
8.3
14.4
24.0
38.4
57.6
96.0
153.6
34
46
63
86
132
197
