2SD2440
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
CER
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter saturation voltage
Transition frequency
Collector output capacitance
Turn-on time
V
CE (sat)
V
BE (sat)
f
T
C
ob
t
on
I
B1
Test Condition
V
CB
= 100 V, I
E
= 0
V
CE
= 80 V, R
BE
= 50
Ω
V
EB
= 15 V, I
C
= 0
I
C
= 50 mA, I
B
= 0
V
CE
= 5 V, I
C
= 0.5 A
V
CE
= 5 V, I
C
= 5 A
I
C
= 5 A, I
B
= 1 A
I
C
= 5 A, I
B
= 1 A
V
CE
= 10 V, I
C
= 0.5 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Output
10
Ω
Min
―
―
―
60
200
20
―
―
―
―
―
Typ.
―
―
―
―
―
―
―
―
5
71
1
Max
10
5
2
―
900
100
1.2
2.5
―
―
2
V
V
MHz
pF
Unit
µA
mA
µA
V
20 µs
Input
I
B2
I
B1
I
B2
Switching time
Storage time
t
stg
―
2
4
µs
V
CC
= 50 V
Fall time
t
f
I
B1
=
−I
B2
= 0.5 A, duty cycle
≤
1%
―
1
3
Note: h
FE (1)
classification
GR: 200 to 400, BL: 300 to 600, V: 450 to 900
Marking
Ｄ2440
Part No. (or abbreviation code)
Lot No.
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
Characteristics
indicator
2
2004-07-07
2SD2440
