CHIP ALUMINUM ELECTROLYTIC CAPACITORS
JZV
JZV
SERIES
105℃ Low Impedance, High Temperature Reflow Soldering
◆FEATURES
・
Load Life : 105℃ 2000 hours.
・
High Temperature reflow soldering is available.
・
Available for high density mounting.
・
Prescribe Impedance value at 100 kHz.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−55∼＋105℃
6.3∼35Vdc
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝0.01CV
or 3μA whichever is greater. (After 2 minutes application of rated voltage)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
120Hz）
6.3 10 16 25 35
（20℃，
(Vdc)
tanδ
0.26 0.19 0.16 0.14 0.12
After applying rated voltage with rated ripple current for 2000 hours at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Rated Voltage
6.3
(Vdc)
Z
（−25℃） （20℃） 2
/Z
Z
（−40℃） （20℃） 3
/Z
Z
（−55℃） （20℃） 4
/Z
Within ±30％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
(tanδ)
Dissipation Factor(MAX)
10
2
3
4
16
2
3
4
25
2
3
3
35
2
3
3
（120Hz）
Low Temperature Stability
Impedance Ratio(MAX)
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆MARKING
100k≦
1.00
1.00
1.00
1.00
AA
47
CJZ
Lot No.
Capacitance
Series
※
Rated voltage code
Negative
120
0.30
0.32
0.50
0.60
1k
0.60
0.75
0.80
0.85
10k
0.80
0.90
0.95
0.95
※Voltage Code
4.7μF
Coefficient
10∼47μF
100μF
220∼1000μF
Rated Voltage
6.3
(Vdc)
Rated Voltage code
j
10
A
16
C
25
E
35
V
◆PART NUMBER
□□□
Rated Voltage
JZV
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
D×L
Case Size
CHIP ALUMINUM ELECTROLYTIC CAPACITORS
JZV
(mm)
◆DIMENSIONS
L MAX
A
1±0.2
φD
4
C
φD＋0.5MAX
L
A1
B1
C
W1
P
6.1 4.3 4.3 1.8 0.5∼0.8 1.0
6.1 5.3 5.3 2.2 0.5∼0.8 1.3
8
6.6 6.6 2.7 0.5∼0.8 1.8
5
6.3
B
1±0.2
6.3 6.1 6.6 6.6 2.7 0.5∼0.8 1.8
8 10.5 8.3 8.3 2.9 0.8∼1.1 3.1
10 10.5 10.3 10.3 3.2 0.8∼1.1 4.5
0.3MAX
W
1
0.5MAX
◆STANDARD SIZE
Vdc
Cap
(μF)
22
47
100
220
330
1000
33
220
10
470
680
1000
10
22
33
47
16
100
220
330
470
680
Size φD×L(mm), Rated Ripple Current (mA r.m.s./105℃, 100kHz), Impedance(Ω MAX/20℃, 100kHz)
C
P
Size
(φDXL)
4×6.1
4×6.1
5×6.1
5×6.1
6.3×6.1
6.3×6.1
6.3×8
6.3×8
8×10.5
4×6.1
6.3×8
8×10.5
8×10.5
10×10.5
4×6.1
4×6.1
5×6.1
5×6.1
5×6.1
6.3×6.1
6.3×6.1
6.3×8
6.3×8
8×10.5
8×10.5
10×10.5
Ripple
90
90
170
170
250
250
300
300
600
90
300
600
600
850
90
90
170
170
170
250
250
300
300
600
600
850
Impedance
1.35
1.35
0.70
0.70
0.36
0.36
0.34
0.34
0.16
1.35
0.34
0.16
0.16
0.08
1.35
1.35
0.70
0.70
0.70
0.36
0.36
0.34
0.34
0.16
0.16
0.08
Vdc
Cap
(μF)
33
47
Size
(φDXL)
5×6.1
6.3×6.1
6.3×6.1
6.3×8
8×10.5
8×10.5
10×10.5
4×6.1
4×6.1
5×6.1
5×6.1
6.3×6.1
6.3×6.1
6.3×6.1
6.3×8
6.3×8
8×10.5
8×10.5
10×10.5
Ripple
170
250
250
300
600
600
850
90
90
170
170
250
250
250
300
300
600
600
850
Impedance
0.70
0.36
0.36
0.34
0.16
0.16
0.09
1.45
1.45
0.70
0.70
0.36
0.36
0.36
0.34
0.34
0.16
0.16
0.09
25
100
220
330
470
4.7
10
22
6.3
35
33
47
100
220
330
