Capable of modulation operation from DC to 2.5Gbps
TO-46 tilt window metal can component, prealigned into SC Sleeve
Designed for drive currents between 3-15mA average
Packaged with a back monitor
Attenuated window can
These products are high-performance 850nm VCSELs (Vertical Cavity Surface-Emitting Lasers) designed for high-speed data
communications and packaged with a custom designed power monitor diode. The power monitor diode can be used with appropriate
feedback control circuitry to set a maximum power level for the VCSEL. These combined features simplify design for high data rate
communication and eye safety.
These products are high radiance VCSELs designed to convert electrical current into optical power that can be used in fiber optic
communications and other applications. As the current varies above threshold, the light intensity increases proportionally.
These products are designed to be used with inexpensive silicon or gallium arsenide detectors, but excellent performance can also be
achieved with some indium gallium arsenide detectors (see HFD3381-002 and HFD3381-102 product data sheets).
The low drive current requirement makes direct drive from PECL (Positive Emitter Coupled Logic) or ECL (Emitter Coupled Logic)
gates possible and eases driver design.
VCSELs produce circularly symmetric, non-astigmatic, narrow divergence beams that, with appropriate lensing, fiber couple all of the
emitter power. These SC TOSA products are pre-aligned and focused fiber optic transmitters designed to interface with 50/125 and
62.5/125µm multi-mode fiber
ABSOLUTE MAXIMUM RATINGS
Parameter
Storage temperature
Operating temperature
Lead solder temperature
Laser continuous average current
Laser peak forward current with pulse width less
than 1µs
Laser reverse voltage
Rating
-40°C to +85°C
-40°C to +85°C,
See note 1 (page 3)
260°C, 10 seconds
12mA
18mA
5V
NOTICE
Stresses greater than those listed under “Absolute Maximum Ratings” may
cause permanent damage to the device. This is a stress rating only and
functional operation of the device at these or any other conditions above those
indicated in the operations section for extended periods of time may affect
reliability.
LASER RADIATION
AVOID EXPOSURE TO BEAM
CLASS 3B LASER PRODUCT
Honeywell
www.honeywell.com/VCSEL
email : VCSEL@honeywell.com
10/15/03
for application support:
Page Number 1
1-866-MY-VCSEL (toll free for US)
Direct Dial (international): 972-470-4660
InnovativeInnov
Innovative VCSEL Solutions
........ Delivered
HONEYWELL VCSEL OPTICAL PRODUCTS
2.5Gbps 850nm VCSEL
SC TOSA
HFE4390-541, HFE4391-541
ELECTRO-OPTICAL CHARACTERISTICS (T
A
=25
o
C unless otherwise stated)
VCSEL Parameters
Average Fiber Coupled
Power
Minimum coupling
efficiency including
wiggle
Threshold Current
Threshold Current
maximum deviation from
25
o
C value
Temperature at minimum
threshold current
Slope Efficiency
Test Condition
I
F
= 7mA
I
F
= 7mA
Symbol
P
OC
55
Min.
Typ.
0.500
Max.
Units
mW
%
Notes
2
2
T
A
= 0 C to 70 C
T
A
= 25
o
C to 85
o
C
T
A
= -40
o
C to 25
o
C
o
o
I
TH
∆I
TH
∆I
TH
∆I
TH
T
O
η
η
η
∆η/∆T
λ
P
∆λ
P
/∆T
∆λ
V
F
P
max
t
r
t
f
RIN
R
S
R
S
R
S
∆R
s
/∆T
Symbol
I
PD
I
PD
I
PD
∆I
PD
/∆T
Deltrk
I
D
C
0.5
-0.5
1.8
-5
0.04
0.06
-4000
830
850
0.06
0.125
2.5
1
1.7
2.5
65
0.16
0.235
mA
mA
mA
mA
o
C
mW/mA
mW/mA
mW/mA
ppm/
o
C
nm
nm/
o
C
3
3
3
3
4
Slope Efficiency
Temperature variation
Peak Wavelength
λ
P
Temperature Variation
Spectral Bandwidth, RMS
Laser Forward Voltage
Rollover
Rise and Fall Times
Relative Intensity Noise
Series Resistance
T
A
= 25
o
C
T
A
= -40
o
C
T
A
= 85
o
C
T
A
= 0
o
C to 70
o
C
I
F
= 7mA,
T
A
= 0
o
C to 85
o
C
I
F
= 7mA,
T
A
= -40
o
C to 85
o
C
I
F
= 7mA
I
F
= 7mA
Pavg = 0.625mW,
Extinction Ratio = 10
1 GHz BW, I
F
= 7mA
I
F
= 7mA , T
A
= 25
o
C
T
A
= -40
o
C
T
A
= 85
o
C
I
F
= 7mA,
T
A
= 0
o
C to 70
o
C
Test Condition
Po = 0.625mW, T
A
= 25
o
C
Po = 0.625mW, T
A
= -40
o
C
Po = 0.625mW, T
A
= +85
o
C
Po = 0.625mW, 0
o
C to
70
o
C
Po = 0mW, V
R
= 3V
V
R
= 0V, Freq = 1MHz
V
R
= 3V, Freq = 1MHz
5
860
1.8
1.25
0.65
2.0
130
150
-122
50
60
nm
V
mW
ps
dB/Hz
Ω
Ω
Ω
ppm/
o
C
Units
mA
mA
%/
o
C
6
7
25
20
-130
35
Series Resistance
Temperature Coefficient
Photodiode Parameters
Monitor Current
-3000
Min.
0.1
TBD
TBD
TBD
TBD
75
40
20
100
55
Typ.
Max.
0.6
TBD
TBD
8
Notes
10
10
10
10
10, 11
Monitor current
Temperature Variation
Monitor Current Tracking
Dark Current
PD Capacitance
nA
pF
Honeywell
www.honeywell.com/VCSEL
email : VCSEL@honeywell.com
10/15/03
for application support:
Page Number 2
1-866-MY-VCSEL (toll free for US)
Direct Dial (international): 972-470-4660
InnovativeInnov
Innovative VCSEL Solutions
........ Delivered
HONEYWELL VCSEL OPTICAL PRODUCTS
2.5Gbps 850nm VCSEL
SC TOSA
HFE4390-541, HFE4391-541
Notes:
1) Reliability is a function of temperature, see
www.honeywell.com/VCSEL
for details.
2) For the purpose of these tests, I
F
is DC current.
3) Threshold current varies as (T
A
– T
O
)
2
. It may either increase or decrease with temperature, depending upon relationship of T
A
to
T
O
. The magnitude of the change is proportional to the threshold at T
O
.
4) Slope efficiency is defined as
∆P
O
/∆I
F
.
5) To compute the value of Slope Efficiency at a temperature T, use the following equation:
η(T) ≈ η(25
o
C)*[1+(∆η/∆ T)*(T-25)]
6) Rollover is the power at which a further current increase does not result in a power increase.
7) Rise and fall times specifications are the 20% - 80%. Most of the devices will measure <135ps fall time. Rise and fall times are
sensitive to drive electronics.
8) To compute the value of Series Resistance at a temperature T, use the following equation:
R
S
(T)
≈
R
S
(25
o
C)*[1+(∆R
S
/ ∆T)*(T-25)]
9) Beam divergence is defined as the total included angle between the 1/e
2
intensity points.
10) These specifications are for the TO-46 component alone. Reflections introduced by any subsequent higher level assembly may
affect these values.
11) Monitor current tracking is defined as follows:
Deltrk
=
I
PD
(P
O
=
0.75mW) / 0.75mW
I
PD
(P
O
=
0.45mW) / 0.45mW
TYPICAL PERFORMANCE CURVES:
Emitted Power vs. Current:
Power varies approximately
Threshold Current vs. Temperature:
Threshold
linearly with current above threshold.
current varies parabolically with temperature; thus it can
be nearly constant for a limited temperature range.
Pmax
Threshold Current
η
I
T H
≈
I
M IN
[1 . 1 × 1 0
- 4
(T -T
M IN
)
2
+ 1 ]
Typical operating current / power
T
M IN
, I
M IN
I
th
Current
T e m p e r a tu r e
Honeywell
www.honeywell.com/VCSEL
email : VCSEL@honeywell.com
10/15/03
for application support:
Page Number 3
1-866-MY-VCSEL (toll free for US)
Direct Dial (international): 972-470-4660
InnovativeInnov
Innovative VCSEL Solutions
........ Delivered
HONEYWELL VCSEL OPTICAL PRODUCTS
2.5Gbps 850nm VCSEL
SC TOSA
HFE4390-541, HFE4391-541
ORDER GUIDE:
Catalog Listing
HFE4390-541
HFE4391-541
Description
SC TOSA with attenuated TO-46 component, VCSEL with Back Monitor Photodiode, Anode of VCSEL
common with Photodiode Cathode
SC TOSA with attenuated TO-46 component, VCSEL with Back Monitor Photodiode, Cathode of
VCSEL common with Photodiode Anode
MOUNTING DIMENSIONS
(for reference only):
All dimensions are in inches.
PINOUT
HFE4390-541
Number
1
2
3
Function
K
LD
K
PD
, A
LD
A
PD
HFE4391-541
Number
1
2
3
Function
A
LD
K
LD
, A
PD
K
PD
LEAD DESCRIPTIONS
A
LD
K
LD
VCSEL Anode
VCSEL Cathode
A
PD
K
PD
Monitor Photodiode Anode
Monitor Photodiode Cathode
Honeywell
www.honeywell.com/VCSEL
email : VCSEL@honeywell.com
10/15/03
for application support:
Page Number 4
1-866-MY-VCSEL (toll free for US)
Direct Dial (international): 972-470-4660
InnovativeInnov
Innovative VCSEL Solutions
........ Delivered
HONEYWELL VCSEL OPTICAL PRODUCTS
2.5Gbps 850nm VCSEL
SC TOSA
HFE4390-541, HFE4391-541
WARRANTY/REMEDY
Honeywell warrants goods of its manufacture as being free of defective materials and faulty workmanship. Commencing with the date of shipment,
Honeywell’s warranty runs for 18 months. If warranted goods are returned to Honeywell during that period of coverage, Honeywell will repair or
replace without charge those items it finds defective. The foregoing is Buyer’s sole remedy and is
in lieu of all other warranties, expressed or
implied, including those of merchantability and fitness for a particular purpose.
While we provide application assistance, personally and through our literature, it is up to the customer to determine the suitability of the product in
the application.
Specifications may change at any time without notice. The information we supply is believed to be accurate and reliable as of this printing.
However, we assume no responsibility for its use.
HONEYWELL CAPABILITIES
Honeywell VCSEL Optical Products has led the industry in high volume VCSEL technology since 1996. VCSELs (Vertical Cavity
Surface Emitting Lasers) are semiconductor lasers which are impacting advances in optical communication, and sensor applications.
VCSELs’ superior reliability, low drive current, high coupled power, narrow and circularly symmetric beam and versatile packaging
options (including arrays) are enabling solutions not possible with other optical technologies. Honeywell’s advanced capabilities
include
10Gbps serial VCSEL solutions
Proton-implanted and oxide VCSELs
850nm is currently available. 780nm, 670nm and additional wavelengths are in development
Packaging: surface mount, TO, SC, LC, MU, arrays, plastic packaging
Assemblies: chip on board, chip on chip, plastic components and optical subassemblies
All configurations (polarities and attenuation) are available
VCSEL and detector arrays
Long wavelength detectors
Custom packaging options
Covered by one or more of the following U.S. Patents and their foreign counter parts: 5,264,715; 5,903,588; 5,737,348
LOCATIONS
Richardson, TX
- Business unit headquarters, wafer growth, wafer fabrication and TO package assembly
Juarez, Mexico
- SC, LC, MU, SMD, PSMD, PE
Minneapolis, MN
- Materials research
SALES AND SERVICE
Honeywell VCSEL Optical Products serves its customers through a worldwide network of sales offices and distributors. For application assistance,
current specifications, pricing or name of the nearest Authorized Distributor, contact a nearby sales office or call:
