General Purpose Relays
Industrial Relays
Power Relay RM 2/3/7
2/3 pole 10/16A, 2 form C (CO) or 3 form C (CO) contacts
Switching capacity up to 6000VA
DC or AC coil
Mechanical indicator
Push-to-test button
Plug-in version, PCB terminals, chassis- or DIN-rail mount
SCHRACK
n
n
n
n
n
n
Typical applications
Elevator control, power supplies
Approvals
Z
Contact Data
(continued)
RM3
RM7
Mechanical endurance
DC coil
AC coil
F0163-B
VDE Cert. No. 40003144, UL E214025
Technical data of approved types on request
RM2
RM3
20x10
6
operations
10x10
6
operations
RM7
Contact Data
Contact arrangement
3 form C
3 form C
3 CO
3 CO
Rated voltage
400VAC
Max. switching voltage
440VAC
Rated current
16A
10A
16A
Limiting making current, max. 20ms 40A
40A
40A
Switching power
6000VA
3800VA
6000VA
Contact material
AgNi90/10
Min. recommended contact load
24VDC/100mA
Frequency of operation, with/without load
960/6000h
-1
Operate/release time typ., DC coil
15/10ms
Bounce time max., DC coil, form A/form B
4/10ms
Contact ratings
Type
Contact
IEC 61810
RM22 C (CO)
RM22 C (CO)
RM3
C (CO)
RM72 C (CO)
UL 508
RM2
A (NO)
RM2
A (NO)
RM2
A (NO)
RM3
C (CO)
RM3
C (CO)
RM3
A (NO)/B (NC)
RM3
A (NO)/B (NC)
RM7
A (NO)
RM7
A (NO)/B (NC)
RM72 A (NO)
RM72 A (NO)
IEC 60947-5-1
RM72 A (NO)
Load
16A, 400VAC, cosφ=1, DC-coil, 70°C
16A, 400VAC, cosφ=1, AC-coil, 60°C
10A, 400VAC, cosφ=1, 55°C
16A, 400VAC, cosφ=1, 50°C
16A, 277VAC, general purpose, 70°C
16A, 240VAC, 1HP, 70°C
16A, 415VAC, resistive, 70°C
10A, 415VAC, resistive, DC-coil, 70°C
10A, 415VAC, resistive, AC-coil, 55°C
10A, 277VAC, gen. purp., DC-coil, 70°C
10A, 277VAC, gen. purp., AC-coil, 55°C
16A, 415VAC, resistive, 50°C
16A, 277VAC, general purpose, 50°C
250VAC/1.5HP (3ph.) DC-coil, 70°C
28VDC/16A general purpose, 40°C
16A, AC-15 400VAC/5A, same pol., 25°C
Cycles
100x10
3
50x10
3
100x10
3
50x10
3
30x10
3
6.050
100x10
3
100x10
3
100x10
3
30x10
3
30x10
3
100x10
3
30x10
3
10x10
3
6x10
3
6.050
2 form C
2 CO
RM2
Coil Data
Coil voltage range
Operative range, IEC 61810
Coil insulation system according UL
Coil versions, DC coil
Coil code
STD
LED
PD
3)
LED+
bipolar
PD
3)
Coil versions, DC coil, RM2, RM3
006
L06
0A6
LA6
012
L12
0B2
LB2
024
L24
0C4
LC4
048
L48
0E8
LE8
060
L60
0G0
LG0
110
M10
1B0
MB0
221
N21
2C1
NC1
Coil versions, DC coil, RM7
006
L06
0A6
LA6
012
L12
0B2
LB2
024
L24
0C4
LC4
030
-
0D0
-
048
L48
0E8
LE8
060
L60
0G0
LG0
110
M10
1B0
MB0
221
N21
2C1
NC1
Operate voltage, DC coil
Release voltage, DC coil
6 to 220VDC
12 to 400VAC
2
class 130 (B)
Rated
voltage
VDC
6
12
24
48
60
110
220
Coil
resistance
Ω±10%
1)2)
32
110
475
2000
2850
10000
1)
40000
2)
Rated coil
power
W
1.1
1.3
1.2
1.2
1.3
1.2
1.2
1.5
1.7
1.7
1.8
1.7
1.6
1.7
1.6
6
24
12
86
24
345
30
490
48
1340
60
2200
110
7300
220
30000
2)
75% of rated coil voltage
10% of rated coil voltage
1) Coil resistance ±12%, 2) Coil resistance ±15%
3) Protection diode PD; standard polarity: +A1 / -A2
All figures are given for coil without pre-energization, at ambient temperature +23°C
06-2019, Rev. 0619
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
General Purpose Relays
Industrial Relays
Power Relay RM 2/3/7
(Continued)
Coil Data
(continued)
Coil versions, AC coil
Coil code
Rated
STD
LED
voltage
Operate
voltage
50/60Hz
VAC
VAC
Coil versions, AC-coil, RM2, RM3
512
R12
12
9.6/10.2
524
R24
24
19.2/20.4
548
R48
48
38.4/40.8
560
R60
60
48.0/51.0
615
S15
115
92.0/97.8
730
T30
230
184.0/195.5
900
V00
400
320.0/340.0
Coil versions, AC-coil, RM7
512
R12
12
9.6/10.2
524
R24
24
19.2/20.4
548
R48
48
38.4/40.8
560
R60
60
48.0/51.0
615
S15
115
92.0/97.8
730
T30
230
184.0/195.5
900
V00
400
320.0/340.0
1)
SCHRACK
Other Data
Release
Coil
Rated coil
voltage resistance
power
50/60Hz
50/60Hz
VAC
Ω±10%
1)2)
VA
3.6
7.2
14.4
18.0
34.5
69.0
120.0
3.6
7.2
14.4
18.0
34.5
69.0
120.0
24
86
345
544
2000
8300
1)
27500
2)
19.5
80
320
500
1850
7500
23500
2)
2.19/1.86
2.26/ 1.95
2.28/1.97
2.27/1.96
2.37/2.00
2.32/ 1.96
2.31/1.96
2.71/2.27
2.62/2.00
2.60/2.17
2.62/2.20
2.65/2.22
2.69/ 2.26
2.61/2.20
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Ambient temperature
for mounting/handling
-20 to 40°C
in operation
DC coil
-40 to 70°C -40 to 70°C -40 to 60°C
AC coil
-40 to 60°C -40 to 55°C -40 to 50°C
Cold storage, IEC 60068-2-1
16h/-40°C
Dry heat, IEC 60068-2-2
16h/+85°C
Damp heat cyclic , IEC 60068-2-30, Db, Variant 112/12h +25/+55°C
Category of environmental protection
IEC 61810
RTI - dust protected
Vibration resistance (functional)
form A (NO)/form B (NC)
5/2g
5/2g
12/4g
Terminal type
PCB-THT, plug-in,
quick-connect
Cover retention, pull/push force
100/100N
Weight
81g
Resistance to soldering heat THT
IEC 60068-2-20
270°C/10s
Packaging unit
10/25 pcs.
RM2
RM3
RM7
Coil resistance ±12%,
2)
Coil resistance ±15%
All figures are given for coil without pre-energization, at ambient temperature +23°C
Insulation Data
RM2
RM3
RM7
Accessories
For details see datasheet
Accessories Power Relay RM
Note: indicated contact ratings and electrical endurance data for direct
wiring of relays (according IEC 61810-1); for relays mounted on sockets
deratings may apply.
PCB layout / terminal assignment
Bottom view on pins
Initial dielectric strength
between open contacts
between contact and coil
between adjacent contacts
Initial surge withstand voltage
between contact and coil
Clearance/creepage
between contact and coil
between adjacent contacts
Material group of insulation parts
1500Vrms
2500Vrms
2500Vrms
5000V
1500Vrms
2500Vrms
2500Vrms
4000V
≥4.0/14.9mm
≥6.1/7.3mm
IIIa
1500Vrms
2500Vrms
2500Vrms
4000V
S0269-AA
3 form C (CO) contacts
S0269-AB
2 form C (CO) contacts
S0269-AD
2
06-2019, Rev. 0619
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
General Purpose Relays
Industrial Relays
Power Relay RM 2/3/7
(Continued)
Dimensions
Plain cover, plug-in version
PCB version
SCHRACK
S0298-BA
S0298-BB
Cover with mounting brackets, 6.3mm quick connect (4.8mm available)
Cover with DIN-snap-on attachement (6.3mm quick connect only)
horizontal
vertical
S0298-BC
S0298-BD
S0298-BE
Product code structure
Type
Typical product code
RM
7
2
2
730
RM
Power Relay RM 2/3/7
Contact arrangement
2
2 form C contacts (2 CO contacts), 16A
7
3 form C contacts (3 CO contacts), 16A
3
3 form C contacts (3 CO contacts), 10A
Version
0
Discontinued: AgCdO, without test button
1)
3
Discontinued: AgCdO, with test button
1)
2
AgNi 90/10, without test button
7
AgNi 90/10, with test button
Enclosure
2
Plain cover, 4.8mm quick connect terminals
3
Cover with mounting brackets, 4.8mm quick connect terminals
5
Cover with mounting brackets, 6.3mm quick connect terminals
7
PCB version
8
Cover with DIN-snap-on attachment, horizontal, 6.3mm quick connect terminals
9
Cover with DIN-snap-on attachment, vertical, 6.3mm quick connect terminals
Coil
Coil code: please refer to coil versions table
1) AgCdO contacts are discontinued and replaced with AgNi contacts (see PCN E-18-003016)
06-2019, Rev. 0619
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
3
General Purpose Relays
Industrial Relays
Power Relay RM 2/3/7
(Continued)
Product code
RM222012
RM222024
RM225012
RM225024
RM225524
RM225615
RM225730
RM227024
RM227730
RM322024
RM327024
SCHRACK
2 form C
2 CO contacts
16A
Contacts
Cont. material
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
AgNi
Without
test button
Version
Plain cover
4.8 mm terminal
Mounting brackets
quick c. 6.3 mm
Enclosure
PCB version
Plain cover
4.8 mm terminal
Plain cover
4.8 mm terminal
Mounting brackets
quick c. 4.8 mm
Mounting brackets
quick c. 6.3 mm
PCB version
With
test button
Plain cover
4.8 mm terminal
RM722012
RM722024
RM7220C4
RM723024
RM725024
RM725615
RM725730
RM727024
RM727730
RM772012
RM772024
RM772060
RM772524
RM772730
RM772900
RM775730
RM778024
RM778730
RM779730
3 form C
3 CO contacts
10A
3 form C
3 CO contacts
16A
DC-coil
DC-coil
DC-coil
DC-coil
AC-coil
AC-coil
AC-coil
DC-coil
AC-coil
DC-coil
DC-coil
DC-coil
DC-coil
DC-coil (PD)
DC-coil
DC-coil
AC-coil
AC-coil
DC-coil
AC-coil
DC-coil
DC-coil
DC-coil
AC-coil
AC-coil
AC-coil
AC-coil
DC-coil
AC-coil
AC-coil
Coil
12VDC
24VDC
12VDC
24VDC
24VAC
115VAC
230VAC
24VDC
230VAC
24VDC
24VDC
12VDC
24VDC
24VDC
24VDC
24VDC
115VAC
230VAC
24VDC
230VAC
12VDC
24VDC
60VDC
24VAC
230VAC
400VAC
230VAC
24VDC
230VAC
230VAC
Coil
Part number
1-1415546-7
1-1415546-8
1415542-7
1415542-8
1-1415546-9
2-1415546-0
1415542-9
2-1415546-1
2-1415546-2
2-1415546-3
5-1415538-3
3-1415546-1
3-1415546-2
4-1415547-1
3-1415546-3
3-1415546-4
3-1415546-5
3-1415546-6
3-1415546-7
3-1415546-8
3-1415546-9
5-1415544-7
2-1415545-1
1-1415547-8
4-1415546-0
4-1415546-1
1-1415547-9
4-1415546-2
2-1415547-0
4-1415546-3
Mounting brackets
quick c. 6.3 mm
DIN-snap-on
horizontal
DIN-snap-on
vertical
4
06-2019, Rev. 0619
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
京公网安备 11010802033920号
EEWORLD
