CHIP ALUMINUM ELECTROLYTIC CAPACITORS
SKV
SKV
SERIES
105℃ Standard, Lead Free Reflow Soldering
◆FEATURES
・
Load Life : 105℃ 1000 hours.
・
Lead free reflow soldering is available.
・
Available for high density mounting.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−55∼＋105℃
6.3∼50Vdc
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝0.01CV
or 3μA whichever is greater.(After 2 minutes application of rated voltage)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
120Hz）
6.3 10 16 25 35 50
（20℃，
(Vdc)
φ4∼φ6.3 0.30 0.24 0.20 0.16 0.14 0.12
tanδ
φ8, φ10 0.35 0.26 0.20 0.16 0.14 0.12
After applying rated voltage with rated ripple current for 1000 hrs at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Rated Voltage
6.3
(Vdc)
Z
（−25℃） （20℃） 4
/Z
Z
（−40℃） （20℃） 8
/Z
Within ±30％ of the initial value. (φ8,10:±25％)
Not more than 300％ of the specified value. (φ8,10:200％)
Not more than the specified value.
(tanδ)
Dissipation Factor(MAX)
Low Temperature Stability
Impedance Ratio(MAX)
10
3
8
16
2
4
25
2
4
35
2
3
50
2
3
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆MARKING
10k≦
1.50
1.50
1.50
1.20
IAA
47
16V
Series
Lot No.
Capacitance
Rated voltage
（6.3V Marking 6V）
：
Polarity of the terminals
60 50） 120
（
0.50
0.65
0.80
0.80
1.00
1.00
1.00
1.00
500
1.20
1.20
1.20
1.10
1k
1.30
1.30
1.30
1.15
0.47∼1μF
2.2∼4.7μF
Coefficient
10∼47μF
100∼1000μF
◆PART NUMBER
□□□
Rated Voltage
SKV
Series
□□□□□
Capacitance
□
Capacitance Tolerance
□□□
Option
D×L
Case Size
CHIP ALUMINUM ELECTROLYTIC CAPACITORS
SKV
(mm)
◆DIMENSIONS
L MAX
A
1±0.2
φD
φD＋0.5MAX
L
A
1
B
1
C
W
1
P
4
5
5.5 4.3 4.3 1.8 0.5∼0.8 1.0
5.5 5.3 5.3 2.2 0.5∼0.8 1.3
B
1±0.2
P
C
6.3 5.5 6.6 6.6 2.7 0.5∼0.8 1.8
C
8
0.3MAX
W
1
0.5MAX
6.5 8.3 8.3 3.4 0.5∼0.8 2.2
8 10.5 8.3 8.3 2.9 0.8∼1.1 3.1
10 10.5 10.3 10.3 3.2 0.8∼1.1 4.5
◆STANDARD SIZE
Size φD×L(mm), Rated Ripple Current (mA r.m.s./105℃, 120Hz)
Vdc
Cap(μF)
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
8×10.5
210
5×5.5
6.3×5.5
6.3×5.5
37
57
74
8×10.5
8×10.5
10×10.5
195
210
440
4×5.5
23
5×5.5
34
6.3×5.5
6.3×5.5
8×10.5
8×10.5
10×10.5
10×10.5
56
65
185
195
440
460
8×6.5
8×10.5
8×10.5
10×10.5
10×10.5
118
180
190
353
450
8×10.5
10×10.5
10×10.5
180
305
360
4×5.5
5×5.5
20
31
6.3×5.5
48
4×5.5
5×5.5
6.3×5.5
14
24
46
6.3
Size
Ripple
10
Size
Ripple
16
Size
Ripple
25
Size
Ripple
35
Size
Ripple
50
Size
4×5.5
4×5.5
4×5.5
4×5.5
5×5.5
6.3×5.5
8×6.5
8×10.5
8×10.5
10×10.5
8×10.5
10×10.5
Ripple
4.0
8.0
11
13
18
28
70
135
155
180
200
315
10×10.5 480
