TrueNet
®
Augmented Category 6 Patch Cords
For CopperTen
®
8-pair and 20-Pair Termination Blocks
Impedance matched for use in TrueNet
®
structured cabling systems; these CopperTen
®
termination
block patch cords exceed all performance requirements for Augmented Category 6. These cords
allow direct patching capability between CopperTen 8-pair and 20-pair blocks or patching from a
CopperTen termination block to an active device or an RJ45 patch panel. The plug is designed with
integrated strain relievers that prevent the cable from moving at the termination point when the
cable is flexed, safeguarding circuit integrity and guaranteeing maximum performance.
Features
• Meets TIA/EIA and ISO Augment Category 6 requirements
• Protective shroud to assist in protecting the user from electrical transfer on the contacts
• Impedance matched patch cord for maximum throughput
• Flexible strain relief boot maintains proper bend radius to ensure peak performance
• UL 1863 listed
• Durable design to be in operation beyond 20-year product warranty
Spec Sheet
www.adc.com • +1-952-938-8080 • 1-800-366-3891
TrueNet
®
Augmented Category 6 Patch Cords
For CopperTen
®
8-pair and 20-Pair Termination Blocks
Specifications
Environment for use:
Operation temperature range:
Maximum relative humidity:
Insulation resistance:
Flammability rating of plastic housing:
No: of PCB insertion cycles:
Plug Material:
Safety:
Indoors, in dry closed rooms
-10°C to + 60°C
≤93%
non-condensing
100MΩ at 500 VDC
UL 94 V0change
Typically 200
Tough Thermoplastic Polymer
UL1863
Ordering Information
Description
CopperTen 4-pair to CopperTen 4-Pair
CopperTen 4-Pair to CopperTen 4-Pair wired 568B
CopperTen 4-Pair to CopperTen 4-Pair wired 568A
CopperTen 4-pair to RJ45 r
CopperTen 4-Pair to RJ45 Plug wired 568B
CopperTen 4-Pair to RJ45 Plug wired 568A
Sub
XX
for color: BL=Blue, GY=Gray, RD=Red, GN=Green, YL=Yellow, WT=White
Call ADC for additional colors
Sub
YY for length: 04= 4 feet, 07= 7 feet, 10=10 feet, 15=15 Feet, 25=25 feet, 50=50 feet
Call ADC for additional lengths
TP6ATB-XXYY
TP6ATB0XXYY
TP6ATH-XXYY
TP6ATH0XXYY
Catalog Number
Spec Sheet
Website: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our website.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
105810AE
4/08
Original
©
2008
ADC Telecommunications, Inc. All Rights Reserved
