Electrical / Environmental
Surface Mount Multilayer Chip Beads,
0402 - 1812 Industry Sizes
• Operating Temperature Range
• Resistance to Solder Heat
-55°C to +125°C
260°C for 10 sec.
BMB
S
RoH
liant
mp
Co
Specifications / Packaging
0402, 0603, 0805, 1206, 1210, 1806 & 1812 Electrical Characteristics - Standard Speed
Part
Number
BMB0402A-600LF
BMB0402A-121LF
BMB0402A-301LF
BMB0402A-601LF
BMB0402A-102LF
BMB0603A-100LF
BMB0603A-300LF
BMB0603A-400LF
BMB0603A-600LF
BMB0603A-680LF
BMB0603A-800LF
BMB0603A-121LF
BMB0603A-181LF
BMB0603A-221LF
BMB0603A-301LF
BMB0603A-451LF
BMB0603A-601LF
BMB0603A-751LF
BMB0603A-102LF
BMB0805A-070LF
BMB0805A-110LF
BMB0805A-170LF
BMB0805A-260LF
BMB0805A-320LF
BMB0805A-400LF
BMB0805A-600LF
BMB0805A-800LF
BMB0805A-900LF
BMB0805A-121LF
BMB0805A-151LF
BMB0805A-181LF
Impedance
Z
W
± 25%
@ 100 MHz
60
120
300
600
1000
10
30
40
60
68
80
120
180
220
300
450
600
750
1000
7
11
17
26
32
40
60
80
90
120
150
180
DCR
W
Max.
0.35
0.40
0.80
1.00
1.50
0.05
0.08
0.10
0.10
0.10
0.10
0.15
0.30
0.30
0.35
0.40
0.45
0.60
0.60
0.05
0.05
0.05
0.05
0.05
0.05
0.15
0.15
0.15
0.15
0.15
0.20
Rated
Current
mA Max.
300
300
200
200
100
600
600
600
600
600
600
600
300
300
300
300
200
100
100
800
800
800
800
800
800
800
800
800
800
800
500
7” Reel
Qty
(Units)
10K
10K
10K
10K
10K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
4K
Part
Number
BMB0805A-221LF
BMB0805A-301LF
BMB0805A-401LF
BMB0805A-601LF
BMB0805A-102LF
BMB0805A-152LF
BMB0805A-202LF
BMB0805A-222LF
BMB1206A-260LF
BMB1206A-310LF
BMB1206A-500LF
BMB1206A-700LF
BMB1206A-900LF
BMB1206A-121LF
BMB1206A-151LF
BMB1206A-201LF
BMB1206A-601LF
BMB1206A-801LF
BMB1206A-102LF
BMB1206A-122LF
BMB1206A-152LF
BMB1206A-202LF
BMB1210A-310LF
BMB1210A-600LF
BMB1210A-900LF
BMB1806A-800LF
BMB1806A-101LF
BMB1806A-151LF
BMB1812A-700LF
BMB1812A-121LF
Impedance
Z
W
± 25%
@ 100 MHz
220
300
400
600
1000
1500
2000
2200
26
31
50
70
90
120
150
200
600
800
1000
1200
1500 @ 50MHz
2000 @ 30MHz
31
60
90
80
100
150
70
120
DCR
W
Max.
0.20
0.20
0.30
0.30
0.35
0.40
0.50
0.50
0.05
0.05
0.08
0.10
0.15
0.15
0.15
0.20
0.30
0.30
0.40
0.40
0.50
0.50
0.30
0.30
0.30
0.10
0.20
0.30
0.40
0.40
Rated
Current
mA Max.
500
500
500
500
300
300
200
200
600
600
600
600
500
500
500
500
500
200
200
200
200
200
400
400
400
400
300
200
200
200
7” Reel
Qty
(Units)
4K
4K
4K
4K
4K
4K
4K
4K
3K
3K
3K
3K
3K
3K
3K
3K
3K
3K
3K
3K
3K
3K
2K
2K
2K
2K
2K
2K
1K
1K
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
139
We reserve the right to change specifications without prior notice.
Specifications / Packaging
0603, 0805 & 1206 Electrical Characteristics - High Speed
Part
Number
BMB0603B-121LF
BMB0603B-301LF
BMB0603B-601LF
BMB0805B-121LF
BMB0805B-301LF
Impedance
Z
W
± 25%
@ 100 MHz
120
300
600
120
300
DCR
W
Max
Rated
Current
mA Max.
200
200
200
200
200
7” Reel
Qty
(Units)
4K
4K
4K
4K
4K
Part
Number
BMB0805B-601LF
BMB0805B-102LF
BMB1206B-121LF
BMB1206B-301LF
BMB1206B-601LF
Impedance
Z
W
± 25%
@ 100 MHz
600
1000
120
300
600
DCR
W
Max
Rated
Current
mA Max.
200
200
200
200
200
7” Reel
Qty
(Units)
4K
4K
3K
3K
3K
0.45
0.45
0.50
0.25
0.25
0.35
0.45
0.20
0.30
0.45
Outline Dimensions (Inch/mm)
Part #
BMB 0402
(1005)
BMB 0603
(1608)
BMB 0805
(2012)
BMB 1206
(3216)
BMB 1210
(3225)
BMB 1806
(4516)
BMB 1812
(4532)
A Dim.
.04 ± .004
1.0 ± .10
.063 ± .006
1.6 ± 0.15
.079 ± .008
2.0 ± 0.2
.126 ± .008
3.2 ± 0.2
.126 ± .008
3.2 ± 0.2
.18 ± .010
4.5 ± 0.25
.18 ± .010
4.5 ± 0.25
B Dim.
.02 ± .004
.50 ± .10
.031 ± .006
.80 ± 0.15
.049 ± .008
1.25 ± 0.2
.063 ± .008
1.6 ± 0.2
.098 ± .008
2.5 ± 0.2
.063 ± .008
1.6 ± 0.2
.126 ± .010
3.2 ± 0.25
C Dim.
.02 ± .004
.50 ± .10
.031 ± .006
.80 ± 0.15
.035 ± .008
.90 ± 0.2
.043 ± .008
1.1 ± 0.2
.051 ± .008
1.3 ± 0.2
.063 ± .008
1.6 ± 0.2
.06 ± .010
1.5 ± 0.25
D Dim.
.01 ± .004
.25 ± .10
.012 ± .008
.30 ± .20
.020 ± .012
.50 ±.30
.020 ± .012
.50 ± .30
.020 ± .012
.50 ± .30
.024 ± .016
.60 ± .40
.024 ± .016
.60 ± .40
Ordering Information
BMB
Model Series
Body Dimensions:
Length (A) x Width (B)
1812
A - 121
LF
Lead-Free
Impedance (W)
Material Characteristics:
A: Standard Speed
B: High Speed
140
MAGNETIC COMPONENTS SELECTOR GUIDE 2009/10 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
