Plugs & In-Line Sockets (Quick Lock Type)
Unit:mm
TCP6100 Series Plugs
13
φ
A
φ
11.8
TCP6180-01-1120
6.2
4.8
24.3
35.5
49.5
Number of Contact
Suitable Cord
Color
Dia. A
Black
Gray#1
Gray#2
3
1
4
4
2
4
2
1
5a
5
3
5
3
1
6
6
4
2
5
3
1
6
7
7
4
2
6
3
1
φ
5.2
φ
10
13
8a
7
4
2
8
5
4.8mm
TCP6140-01-1120
TCP6140-01-1220
TCP6140-01-1320
TCP6150-01-1120
TCP6150-01-1220
TCP6150-01-1320
TCP6160-01-1120
TCP6160-01-1220
TCP6160-01-1320
TCP6170-01-1120
TCP6170-01-1220
TCP6170-01-1320
TCP6180-01-1120
TCP6180-01-1220
TCP6180-01-1320
Notes:
1. Wires are connected to the contacts by soldering.
2. Parts, not assembled, are sold in a set. For the package style, refer
please the specification.
3. Combinations with sockets
A. Can be fit with the TCS6100 series (see page 25 to 26).
B. The combinations of the 8P (a) plug and the 7P socket are not
designed for error connecting prevention.
TCS61
5 Series In-Line Sockets
13.6
5.5
30.5
φA
TCS6185-01-1120
Number of Contact
Suitable Cord
Color
Dia. A
Black
Gray#1
Gray#2
4
2
4
3
1
2
6
13.6
6
5
7
7
65
8
φ
5.2
41.5
14
8a
76
4
4
3
1
4
2
1
3
5
2
1
3
4.8mm
TCS6145-01-1120
TCS6145-01-1220
TCS6145-01-1320
TCS6165-01-1120
TCS6165-01-1220
TCS6165-01-1320
TCS6175-01-1120
TCS6175-01-1120
TCS6175-01-1120
TCS6185-01-1120
TCS6185-01-1120
TCS6185-01-1120
Notes:
1. Wires are connected to the contacts by crimping. The types of the con-
tacts are shown in the table below.
2. The contacts are optional. To crimp the contacts, a special tool is
required.
3. Combinations with plugs
A. Can be fit with the TCP6100 series (see page 26).
B. The combinations of the 8P (a) plug and the 7P socket are not
designed for error connecting prevention.
Part No. of Contact Applicable Wire Size Finished Outside Diameter
AWG #26∼30
φ1
max.
TCS9200-10-010
AWG #22∼24
φ1.3
max.
TCS9200-11-010
6
All
3∼6
7
All
3∼7
8a
All
3∼8
