Multi-layer Chip Inductors - Ferrite
ctparts.com
CTML1210 Series
From .12 µH to 33 µH
Part
Number
CTML1210-R12K
CTML1210-R15K
CTML1210-R18K
CTML1210-R22K
CTML1210-R27K
CTML1210-R33K
CTML1210-R39K
CTML1210-R47K
CTML1210-R56K
CTML1210-R68K
CTML1210-R82K
CTML1210-1R0K
CTML1210-1R2K
CTML1210-1R5K
CTML1210-1R8K
CTML1210-2R2K
CTML1210-2R7K
CTML1210-3R3K
CTML1210-3R9K
CTML1210-4R7K
CTML1210-5R6K
CTML1210-6R8K
CTML1210-8R2K
CTML1210-100K
CTML1210-120K
CTML1210-150K
CTML1210-180K
CTML1210-220K
CTML1210-270K
CTML1210-330K
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±10% tolerance only.
Inductance
(µH)
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
12.0
15.0
18.0
22.0
27.0
33.0
L Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
Q
Factor
Min.
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
Q Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
SRF
Min.
(MHz)
500
450
400
350
320
300
250
220
180
160
140
120
100
85
80
75
70
60
55
50
47
43
40
36
33
30
27
25
20
17
DCR
Max.
Ω
(Ω)
0.22
0.25
0.28
0.32
0.36
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.85
0.90
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
2.10
2.50
2.80
3.30
3.70
5.00
5.60
Rated
DC
(mA)
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
170
150
140
130
120
110
80.0
70.0
CHARACTERISTICS
Description:
Ferrite core, multi-layer chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, RF filters, disk drives, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-25°C to +125°C
Inductance Tolerance:
±10%
Testing:
Inductance and Q are tested on an HP4285A or
HP4286A at specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
3.20±0.2
0.126±0.008
B
2.50±0.2
0.098±0.008
C
1.30±0.2
0.051±0.008
D
0.5±0.3
0.02±0.3
D
C
PAD LAYOUT
4.4
(0.173)
A
B
3.4
(0.134)
2.2
(0.087)
07.22.04
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2004 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
