Shielded magnetic circuit reduces leakage flux, Fe base metal
core enables high saturation and metalized core termination
results in excellent shock resistance
Electrical Specifications @ 25°C
—
Operating Temperature -40°C to 125°C
PART NUMBER
PA4330.471NLT
PA4330.681NLT
PA4330.102NLT
PA4330.222NLT
NOTES:
INDUCTANCE
1MHz, 1V
uH +/-20%
0.47
0.68
1
2.2
RATED
CURRENT
A
3.1
2.8
2.35
1.7
MIN.
SELF-RESONANT
FREQUENCY
MHz
102
77
70
39
DC
RESISTANCE
MAX.
TYP.
mΩ
49
65
90
170
mΩ
41
57
75
142
SATURATION CURRENT
(20°C)
A
3.8
3.5
3.35
1.8
HEATING CURRENT
20°C Rise
A
2.7
2.5
2.05
1.45
40°C Rise
A
3.1
2.8
2.35
1.7
1. Actual temperature of the component during system operation (ambient plus temperature rise)
must be within the standard operating range.
2. The rated current as listed is either the saturation current (20°C) or the heating current (40°C Rise)
depending on which value is lower.
3. The saturation current is the current at which the initial inductance drops approximately 30% at the
stated ambient temperature. This current is determined by placing the component in the specified
ambient environment and applying a short duration pulse current (to eliminate self-heating effect)
to the component.
4. The heating current is the DC current required to raise the component temperature by approximately
20°C or 40°C. Take note that the components’ performance varies depending on the system condi-
tions. It is suggested that the component be tested at the system level, to verify the temperature
rise of the component during system operation.
5. Maximum voltage across terminals to be limited to <25Vdc.
Mechanical
PA43330.XXXNLT
B
C
D
G
E
H
Schematic
1
2
A
F
J
E
H
FINAL OUTLINE
SUGGESTED PAD LAYOUT
Part Number
PA4330.XXXNLT
A (max)
2.2 MAX
B (max)
1.8 MAX
C
1.0 MAX
D
(1.5)
E
(0.6)
F
(0.8)
G
(1.70)
H
(0.7)
J
(0.7)
1
pulseelectronics.com
P749.B (05/15)
Pulse Jack
Shielded Drum Core Inductor
PA4330.XXXNLT Series
TAPE & REEL INFO
T
E
P
2
P
0
ØD
0
Electronics
B
F
W
A
N
K
0
P
1
G
SURFACE MOUNTING TYPE, REEL/TAPE LIST
TYPE
PA4330.XXXNLT
REEL SIZE (mm)
A
Ø178
B
14.4
G
8.4
N
58
E
1.75
F
3.5
D
0
1.5
P
4
TAPE SIZE (mm)
P
0
4
P
2
2
W
8
T
0.25
K
0
1.2
QTY
PCS/REEL
2000
For More Information
Pulse Worldwide
Headquarters
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
Pulse China Headquarters
Pulse North China
Pulse South Asia
Pulse North Asia
B402, Shenzhen Academy of
Room 2704/2705
135 Joo Seng Road
3F, No. 198
Aerospace Technology Bldg.
Super Ocean Finance Ctr.
#03-02
Zhongyuan Road
10th Kejinan Road
2067 Yan An Road West
PM Industrial Bldg.
Zhongli City
High-Tech Zone
Shanghai 200336
Singapore 368363
Taoyuan County 320
Nanshan District
China
Taiwan R. O. C.
Shenzhen, PR China 518057
Tel: 886 3 4356768
Tel: 858 674 8100
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Tel: 86 21 62787060
Tel: 65 6287 8998
Fax: 886 3 4356823 (Pulse)
Fax: 858 674 8262
Fax: 49 7032 7806 12
Fax: 86 755 33966700
Fax: 86 2162786973
Fax: 65 6287 8998
Fax: 886 3 4356820 (FRE)
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be
