2mm LOW PROFILE
TMM SERIES
SPECIFICATIONS
For complete specifications
see www.samtec.com?TMM
Insulator Material:
Black Liquid
Crystal Polymer
FILE NO. E111594
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over 50µ" (1,27µm) Ni
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
Voltage Rating:
500 VAC mated with SQW
450 VAC mated with SQT
RoHS Compliant:
Yes
CURRENT RATING
Mated with
AMBIENT
TEMP
SQT
CLT
3.7A
20°C
5.5A
3.3A
40°C
5A
2.9A
60°C
4A
2.4A
80°C
3A
Mates with:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS, TCSD
Single, double
and quad row
Ultra-low profile
(1,50mm) .059"
TM
APPLICATION
Choice of five
lead styles
APPLICATIONS
SQT TMM
Retention Clip Option (–RC)
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(2,00mm)
.0787" pitch
(2,00mm)
.0787"
HORIZONTAL
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead–Free Solderable:
Yes
TMM
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
LEAD
STYLE
– 01
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
Also Available
Press Fit
See PTT Series.
–L
= 10µ" (0,25µm)
Gold on
contact area,
Matte Tin
on tail
–S
= Single Row
01 thru 50
(1,97)
.078
–RA &
–RE
= Right Angle
(Lead Style
–01 only)
(2 positions
minimum, –Q
row)
–D
= Double Row
Surface
Mount
See TMM Series.
50
02
No. of positions x
(2,00) .0787
A
B
C
–G
= 20µ" (0,51µm)
Gold on
contact area,
Gold flash
on tail
–Q
= Four Row
01
100
–02
– 03
(3,94)
.155
Elevated
See TW Series.
– 04
– 05
– 06
01
99
200
High
Density
See TMMH Series.
(6,00)
.236
04
(3,20) (3,50)
.126 .138
(
8,20)
(3,70) (3,00)
.323 .146 .118
(4,00) (2,70)
.158 .106
(5,69) (1,91)
.224 .075 (2,29)
(5,43) (1,65) .090
.214 .065
(9,58) (3,20) (4,88)
.377 .126 .192
–RC
(3,00)
.120
(3,20)
.126
–T
= Matte Tin
(8,00)
.315
(2,00)
= 30µ" (0,76µm)
.0787
Gold on
contact area,
Matte Tin
on tail
(2,00).0787
–Q –RA
(3,00)
.120
(3,20)
.126
–S
= Retention Clip
(Mates with
TCSD)
(Double row only,
4 positions
minimum, only
available –06
lead style)
(1,27)
.050
–“XXX”
= Polarized
Position
(Specify position
of omitted pin)
Shrouded
Four Row
Vertical &
Right Angle
See TMMS Series.
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
01
197
–RC
(1,50)
.059
(2,00) .0787
(0,50) .020 SQ
(3,00) .120
B
A
C
OPTION
(2,00)
.0787
D
(1,27)
.050
(3,56)
.140
D
–D
–Q
–RA & –RE
– RA
–RE
(2,00) .0787
–S & –Q
–D
–S
