CMDZ4L7BKLEADFREE datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> CMDZ4L7BKLEADFREE

CMDZ4L7BKLEADFREE: DescriptionZener Diode, 4.7V V(Z), 5%, 0.25W,; CategoryDiscrete semiconductor diode; File Size372KB，2 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

CMDZ4L7BKLEADFREE Overview

Zener Diode, 4.7V V(Z), 5%, 0.25W,

CMDZ4L7BKLEADFREE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Central Semiconductor
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	750 Ω
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Maximum operating temperature	150 °C
Maximum power dissipation	0.25 W
Nominal reference voltage	4.7 V
surface mount	YES
Terminal surface	Matte Tin (Sn)
Maximum voltage tolerance	5%
Working test current	0.5 mA

Preview

Download Datasheet

View All

CMDZ1L8 THRU CMDZ47L

SURFACE MOUNT SILICON

LOW LEVEL ZENER DIODE

250mW, 1.8 THRU 47 VOLTS

±5%

TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMDZ1L8 Series

Silicon Low Level Zener Diode is a high quality voltage

regulator, manufactured in a SUPERmini™ surface

mount package, designed for applications requiring a

low operating current, low leakage, and a sharp knee.

MARKING CODE: SEE MARKING CODES ON

ELECTRICAL CHARACTERISTICS TABLE

SOD-323 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNIT

°C

°C/W

250

-65 to +150

500

ELECTRICAL CHARACTERISTICS:

(TA=25°C), VF=0.9V Max @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

CMDZ1L8

CMDZ2L0

CMDZ2L2

CMDZ2L4

CMDZ2L5

CMDZ2L7

CMDZ2L8

CMDZ3L0

CMDZ3L3

CMDZ3L6

CMDZ3L9

CMDZ4L3

CMDZ4L7

CMDZ5L1

CMDZ5L6

CMDZ6L2

CMDZ6L8

CMDZ7L5

CMDZ8L2

CMDZ9L1

CMDZ10L

CMDZ11L

CMDZ12L

CMDZ13L

CMDZ15L

1.710

1.900

2.090

2.280

2.375

2.565

2.660

2.850

3.135

3.420

3.705

4.085

4.465

4.845

5.320

5.890

6.460

7.125

7.790

8.645

9.50

10.45

11.40

12.35

14.25

NOM

1.8

2.0

2.2

2.4

2.5

2.7

2.8

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

MAX

1.890

2.100

2.310

2.520

2.625

2.835

2.940

3.150

3.465

3.780

4.095

4.515

4.935

5.355

5.880

6.510

7.140

7.875

8.610

9.555

10.50

11.55

12.60

13.65

15.75

TEST

CURRENT

MAXIMUM

ZENER

IMPEDANCE

ZZT @ IZT

1200

1100

1000

900

750

400

325

MAXIMUM

REVERSE

CURRENT

IR @ VR

μA

5.0

1.0

1.5

2.0

3.5

6.0

8.0

10.5

11.5

MAXIMUM

TEMPERATURE

COEFFICIENT

ΘV

%/°C

-0.085

-0.080

-0.065

-0.060

±0.055

±0.030

+0.038

+0.045

+0.050

+0.058

+0.062

+0.068

+0.075

+0.076

+0.077

+0.079

+0.082

TYPE

MARKING

CODE

IZT

μA

500

R10 (21-October 2010)
