CMPZDA18VBKTIN/LEAD datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> CMPZDA18VBKTIN/LEAD

CMPZDA18VBKTIN/LEAD: DescriptionZener Diode, 18V V(Z), 5%, 0.35W,; CategoryDiscrete semiconductor diode; File Size390KB，2 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMPZDA18VBKTIN/LEAD Overview

Zener Diode, 18V V(Z), 5%, 0.35W,

CMPZDA18VBKTIN/LEAD Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Reach Compliance Code	unknown
ECCN code	EAR99
Diode type	ZENER DIODE
Maximum dynamic impedance	45 Ω
Maximum operating temperature	175 °C
Maximum power dissipation	0.35 W
Nominal reference voltage	18 V
surface mount	YES
Maximum voltage tolerance	5%
Working test current	5 mA

Preview

Download Datasheet

View All

CMPZDA2V4 THRU CMPZDA47V

SURFACE MOUNT

DUAL, COMMON ANODE

SILICON ZENER DIODES

2.4 VOLTS THRU 47 VOLTS

350mW

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMPZDA2V4

series dual silicon Zener diode is a high quality voltage

regulator, connected in a common anode configuration,

for use in industrial, commercial, entertainment and

computer applications.

MARKING CODE: SEE MARKING CODES ON

ELECTRICAL CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

350

-65 to +175

429

ELECTRICAL CHARACTERISTICS PER DIODE:

(TA=25°C) VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

CMPZDA2V4

CMPZDA2V7

CMPZDA3V0

CMPZDA3V3

CMPZDA3V6

CMPZDA3V9

CMPZDA4V3

CMPZDA4V7

CMPZDA5V1

CMPZDA5V6

CMPZDA6V2

CMPZDA6V8

CMPZDA7V5

CMPZDA8V2

CMPZDA9V1

CMPZDA10V

CMPZDA11V

CMPZDA12V

CMPZDA13V

CMPZDA15V

CMPZDA16V

CMPZDA18V

CMPZDA20V

CMPZDA22V

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.4

7.0

7.7

8.5

9.4

10.4

11.4

12.4

13.8

15.3

16.8

18.8

20.8

MAX

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

11.6

12.7

14.1

15.6

17.1

19.1

21.2

23.3

TEST

CURRENT

MAXIMUM

ZENER IMPEDANCE

MAXIMUM

REVERSE

CURRENT

μA

5.0

2.0

1.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

0.1

0.05

1.0

2.0

4.0

5.0

6.0

7.0

8.0

10.5

11.2

12.6

14.0

15.4

MAXIMUM

ZENER

VOLTAGE

CURRENT

TEMP.

COEFF.

IZM

9.2

8.3

7.6

ΘV

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

0.08

0.09

WW3

WW4

WW5

WW6

WW7

WW8

WW9

ZZ1

ZZ2

ZZ3

ZZ4

ZZ5

ZZ6

ZZ7

ZZ8

ZZ9

YY1

YY2

YY3

YY4

YY5

YY6

YY7

YY8

TYPE

MARKING

CODE

IZT

5.0

ZZT @ IZT

100

ZZK @ IZK

600

500

480

400

150

100

150

170

200

225

250

1.0

R9 (10-August 2012)
