SMD Type
Leadless Power Inductors
H½DI-0520 Series
[RoHS Compliant]
[RoHS Compliant]
●H DI-0520 Series
・
Model
Inductance
at 100kHz,1mA
（μH）
1.2
±
30%
2.2
±
30%
3.3
±
30%
4.7
±
30%
6.8
±
30%
10
±
20%
15
±
20%
22
±
20%
33
±
20%
47
±
20%
68
±
20%
100
±
20%
DC resistance
（Ω）max.
Rated current
（A）
H DI-0520-1R2
・
H DI-0520-2R2
・
H DI-0520-3R3
・
H DI-0520-4R7
・
H DI-0520-6R8
・
H DI-0520-100
・
H DI-0520-150
・
H DI-0520-220
・
H DI-0520-330
・
H DI-0520-470
・
H DI-0520-680
・
H DI-0520-101
・
0.035
0.048
0.062
0.09
0.14
0.16
0.26
0.32
0.54
0.64
1.07
1.87
3.40
2.60
2.00
1.80
1.40
0.90
0.70
0.60
0.40
0.40
0.30
0.20
●Operating temperature range: −20 to +105℃ (Including self-temperature rise)
Shape and Dimensions
1.8
±
0.2
5.0
±
0.3
5.0
±
0.3
(5.8)
(0.8)
(4.1)
(1.15)
[mm]
Recommended Land Pattern
2.0
4.0
6.0
[mm]
Choke Coils VOL.08
●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.
●Please request for a specification sheet for detailed product data prior to the purchase.
●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.
2008.08.29 P0936MCCC10VOL08E
