Image Reject Mixer / SSB Modulator
Communications Band
Electrical Specifications
Parameter
SSB Conversion
loss:
(2) (3)
Image Rejection Sideband
Suppression:
(4)
Isolation
LO to RF:
LO to I/Q:
RF to I/Q:
I/Q to RF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(5)
RF 5.6-9.0 GHz
LO 5.6-9.0 GHz
IF 50-90 MHz
(1)
:
Conditions
RF(GHz)
5.6-9.0
5.8-8.8
5.6-9.0
LO(GHz)
5.6-9.0
5.8-8.8
5.6-9.0
5.6-9.0
5.6-9.0
5.6-9.0
5.6-9.0
5.6-9.0
50-90
50-90
50-90
50-90
IF(MHz)
50-90
70
50-90
Min
Specifications
Typical
5.0 dB
26 dB
23 dB
31 dB
40 dB
26 dB
40 dB
+5 dBm
+8 dBm
+12 dBm
+14 dBm
+17 dBm
+21 dBm
+10 dBm
+13 dBm
+17 dBm
Max
6.0 dB
IRM5xMS-1
LO Power
4 = +10 dBm
6 = +13 dBm
7 = +17 dBm
17 dB
16 dB
25 dB
25 dB
5.6-9.0
5.6-9.0
5.6-9.0
5.6-9.0
MIQ54
MIQ56
MIQ57
MIQ54
MIQ56
MIQ57
MIQ54
MIQ56
MIQ57
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25°C with the
nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss.
3. Conversion loss typically degrades less than 0.5 dB at +100°C and improves less than 0.5 dB at -55°C.
4. Measured with an IF quadrature hybrid whose amplitude and phase errors are 0.5 dB and 3 degrees maximum.
5. Usable LO drives are up to 2 dB below to 3 dB above nominal.
6. See Application notes M112, for aid in selecting the outline and for mounting and installation information
.
Typical Performance at 25°C
IRM5xMS-1
Outline: MS7H
5.0
All dimensions are in inches and [mm].
Specifications subject to change without notice.
