YAGEO CORPORATION
SMD INDUCTOR / BEADS
SMD Power Inductors
SSL0802 Series
For SSL series provide excellent current carrying capabilities in a small footprint. They have a flat
top for reliable pick and place operations and features robust temperature deflection. In addition
to the standard versions shown here, custom inductors are available to meet your exact require-
ment.
fEATURES
High energy storage and very low resistance.
Smallest size and high performance
AppLICATIonS
Notebook computers, Sep-up and step-down converters
Flash, memory programmers. Etc...
pRodUCT IdEnTIfICATIon
SSL
-
-
International No.
Tolerance
Inductance
Packaging Style
Dimensions
Product Symbol
ELECTRICAL CHARACTERISTICS
pART no.
IndUCTAnCE SRf
(µH ± 20%) *
SSL0802T-100M-S
SSL0802T-150M-S
SSL0802T-220M-S
SSL0802T-330M-S
SSL0802T-470M-S
10
15
22
33
47
68
100
150
220
330
470
680
1000
(mHz)
35
33
25
19
14
12
10
8
6
5
4
3
2.5
dC
RESISTAnCE
(Ω
+0
)
0.09
0.12
0.19
0.25
0.32
0.55
0.7
1.0
1.6
2.2
3.3
4.4
7.0
Isat **
(A)
2.4
2.0
1.6
1.4
1.0
0.9
0.7
0.6
0.5
0.4
0.3
0.2
0.1
Irms ***
(A)
2.0
1.5
1.3
1.1
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.05
• Packaging: T : Tape and Reel
• Tolerance: M: ±20%
• Note: YAGEO will start to release SSL Series
inductors with lead-free terminals which
meet SONY SS-00259's criteria for lead-
free product in Q2 of 2004, and YAGEO
Internal No will be changed to “N” as
identification. Ex. SSL04LP-1R2M-N
SHApES And dImEnSIonS
12.95
+0
1st.
SSL0802T-680M-S
SSL0802T-101M-S
SSL0802T-151M-S
9.4
+0
2nd.
3rd.
3.0
+0
SSL0802T-221M-S
SSL0802T-331M-S
SSL0802T-471M-S
2.54
SSL0802T-681M-S
SSL0802T-102M-S
7.62
2.54
Dimensions : mm
* Inductance Tested at 0.1 Vrms, 100 KHz
** Inductance Drop = 10% Typ. at Isat.
*** ∆T = 30°C Rise Typ at Irms.
Operating Temperature Range -40°C to +85°C
265
ELECTRICAL CHARACTERISTICS : LEAd-fREE & RoHS CompLIAnCE
pART no.
SSL0802T-100
SSL0802T-150
SSL0802T-220
SSL0802T-330
SSL0802T-470
SSL0802T-680
SSL0802T-101
SSL0802T-151
SSL0802T-221
SSL0802T-331
SSL0802T-471
SSL0802T-681
SSL0802T-102
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
IndUCTAnCE
(nH)
10
15
22
33
47
68
100
150
220
330
470
680
1000
TEST
fREQUEnCY
(MHZ)
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
100KHz,0.1V
Rdc
Max
0.09
0.12
0.19
0.25
0.32
0.55
0.7
1
1.6
2.2
3.3
4.4
7
Isat
(A)
2.4
2
1.6
1.4
1
0.9
0.7
0.6
0.5
0.4
0.3
0.2
0.1
Irms
(A)
2
1.5
1.3
1.1
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.05
SRf
(KHz)Typ.
35
33
25
19
14
12
10
8
6
5
4
3
2.5
NOTE :
-tolerance M=±20%
1.Operating temperature range -40°C~85°C
2.Inductance drop 20% typ. at last
4. ∆T=30°C rise typ.at Irms.
"-N"FOR COMPLETELY LEAD FREE TYPE(INCLUDING FERRITE BODY & SOLDER)
