STANDARD RF INDUCTORS - SURFACE MOUNT
SMRF3013
SMRF3013LF
*
Wirewound, Molded
PART
NUMBER
SMRF3013-100K
SMRF3013-110J
SMRF3013-120K
SMRF3013-130J
SMRF3013-150K
SMRF3013-160J
SMRF3013-180K
SMRF3013-200J
SMRF3013-220K
SMRF3013-240J
SMRF3013-270K
SMRF3013-300J
SMRF3013-330K
SMRF3013-360J
SMRF3013-390K
SMRF3013-430J
SMRF3013-470K
SMRF3013-510J
SMRF3013-560K
SMRF3013-620J
SMRF3013-680K
SMRF3013-750J
SMRF3013-820K
SMRF3013-910J
SMRF3013-101K
TRADITIONAL
Pb
COMPLIANT
RoHS
L
µH
0.10
0.11
0.12
0.13
0.15
0.16
0.18
0.20
0.22
0.24
0.27
0.30
0.33
0.36
0.39
0.43
0.47
0.51
0.56
0.62
0.68
0.75
0.82
0.91
1.0
Q
MIN
40
40
40
38
38
35
35
33
33
33
33
30
30
30
30
30
30
30
30
28
28
28
28
25
25
TEST
FREQ
MHz
PHENOLIC CORE
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
SRF
MHz
MIN
680
660
640
625
600
580
550
530
510
475
430
420
410
385
365
345
330
310
300
290
275
265
250
240
230
DCR
OHMS
MAX
0.080
0.085
0.090
0.095
0.100
0.110
0.120
0.130
0.140
0.150
0.160
0.190
0.220
0.260
0.300
0.325
0.350
0.420
0.500
0.550
0.600
0.710
0.850
0.925
1.00
CURRENT
RATING
mA DC
1590
1542
1499
1459
1422
1356
1298
1247
1202
1161
1124
1032
959
882
821
789
760
649
636
606
580
534
488
468
450
continued next page
Suffix “J” for 5% tolerance or Suffix “K” for 10% tolerance
Optional tolerances are available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: SMRF3013-100KLF
OVER TERMINAL
MARKING: XXX
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
0.300/0.325
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
(7.62/8.26)
0.125/0.145
(3.18/3.68)
OVER TERMINAL
0.070
(1.78)
REF
Q VS. FREQUENCY
SMRF3013 SERIES
120
0.110/0.130
(2.79/3.30)
MARKING: XXX
0.300/0.325
(7.62/8.26)
OVER TERMINAL
0.125/0.145
(3.18/3.68)
OVER TERMINAL
0.040/0.060 (1.02/1.52) WIDE X
0.020 (0.508) MIN DEEP
2 SIDES
NOTES:
100
1000 µH
0.15 µH
RECOMMENDED FOOT PRINT
0.075 (1.91)
0.100
(2.54)
• Operating Temperature Range:
-55°C to +125°C
80
10 µH
Q
60
40
180 µH
1.0 µH
0.070
(1.78)
REF
0.110/0.130
(2.79/3.30)
20
0.040/0.060 (1.02/1.52) WIDE X
0.020 (0.508) MIN DEEP
2 SIDES
0.310
(7.87)
CENTERS
• Current Rating is based on a 35°C
temperature rise at an ambient
temperature of 90°C
• Epoxy-encapsulated for environmental
protection and superior strength to
withstand all types of reflow soldering
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
2200
8 mm
16 mm
13 in.
0
0.1
1
10
100
Frequency in MHz
1000
RECOMMENDED FOOT PRINT
0.075 (1.91)
0.100
(2.54)
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
