D Subminiature
D*JK — 90° PC Tails — Standard Footprint .318 or .283 inch
Plug
Part Numbers
Shell Size
DE
DA
DB
DC
Layout
9
15
25
37
Through Hole
DEJK9P*-1U0N
DAJK15P*-1U0N
DBJK25P*-1U0N
DCJK37P*-1U0N
Filter D
Clinch Nut
#4-40 UNC
DEJKE9P*-1U0N
DAJKE15P*-1U0N
DBJKE25P*-1U0N
DCJKE37P*-1U0N
* Insert filter designator. Example: DEJK9P4-1U0N (For 1000 pF Filter Capacitance)
Note: For performance class 1 add -A190. Example: DEJK9P1-1U0N-A190
Reader’s Resource
For contact cavity arrangements,
see page 224.
For P.C. hole patterns, see page 272.
For panel cutouts, see page 221.
For hardware views (European),
see page 227.
Filter Designator*
1
2
3
4
5
For electrical data, see page 106.
Filter Capacitance
330 pF
470 pF
680 pF
1000 pF
1500 pF
Engaging Face
3,50 (.138)
2,84 (.112)
7,19 (.283)
W
L
F
Dimensions
Shell Size
DE
DA
DB
DC
A
±0,38
(.015)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
B
±0,13
(.005)
16,92 (.666)
25,25 (.994)
38,96 (1.534)
55,42 (2.182)
C
±0,13
(.005)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
D
±0,13
(.005)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
E
±0,38
(.015)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
F
±0,25
(.010)
10,72 (.422)
10,72 (.422)
10,72 (.422)
10,72 (.422)
W
±0,37
(.015)
6,69 (.264)
6,69 (.264)
—
—
W
±0,41
(.016)
—
—
6,84 (.269)
6,84 (.269)
L
±0,25
(.010)
0,76 (.030)
0,76 (.030)
0,99 (.039)
0,99 (.039)
Connector footprint measured from the front shell.
Connector footprint measured from the rear shell.
108
Dimensions are shown in mm (inch)
Dimensions subject to change
