REVISION AJ
DO NOT
SCALE FROM
THIS PRINT
FIG. 1
-08: 8 ROW
(SEAF-30-05.0-XX-08-1-A-XX-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
No OF POSITIONS
****-10, ***-15, *****-19,
-20, -25, -30, -40, -50
(PER ROW)
LEAD STYLE
-05.0: .199[5.06] HEIGHT
-06.0: .238[6.05] HEIGHT
-06.5: .258[6.55] HEIGHT
.033 0.84
-07.5: .297[7.54] HEIGHT
REF
**-08.0:
.317[8.05] HEIGHT
(SEE TABLE 1)
PLATING SPECIFICATION
-L: LIGHT GOLD IN CONTACT
.100 2.54
AREA, MATTE TIN ON TAIL
(USE SUB-C-209-XX.X-L-X)
REF (TYP)
-SM: SELECTIVE GOLD IN
CONTACT AREA, MATTE TIN
08
ON TAIL. (USE SUB-C-209-XX.X-S-X)
-S: SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAIL.
(USE SUB-C-209-XX.X-S-X)
.200 5.08
REF
ROW
-04: 4 ROWS (SEE FIG.12, SHT 5)
-05: 5 ROWS (SEE FIG. 6, SHT 3)
-06: 6 ROWS (SEE FIG. 5, SHT 3)
01
-08: 8 ROWS (SEE FIG. 1)
.074 1.88 -10: 10 ROWS (SEE FIG. 2, SHT 2)
REF
TAPE & REEL
(SEE NOTES 8, 9 & 10)
POLYIMIDE PAD
(SEE FIG. 4, SHT 2)
(SEE NOTE 7)
OPTION
-LP: LATCH POST OPTION
(SEE FIG. 13, SHT 5)
(ONLY AVAILABLE WITH -O5.O
LEAD STYLE, 6, & 8 ROWS)
**-N: NOTCH
(SEE FIG.7, SHT 4)
(ONLY AVAILIBLE IN
SEAF-30-05.0-XX-06-X-XX)
(No OF POS x .050[1.27]) + .229[5.82] REF
.156 3.96 REF
.033 0.84 REF
.361 9.17
REF
C
(No OF POS -1) x .0500[1.270] (TYP)
.0500 1.270 (TYP)
C
C
L
"A"
.421 10.69
REF
C
L
.125 3.18
REF
"A"
(No OF POS x .050[1.27]) + .170[4.32] REF
(No OF POS x .050[1.27]) + .210[5.33] REF
SEAF-XX-XX.X-08
AJ
ALIGNMENT PIN
(SEE FIG. 3, SHT 2)
(SEE NOTE 6)
(NOT AVAILABLE WITH -19 POSITION)
'B'
"A"
REF
C
**
= NOT RELEASED FOR PRODUCTION.
***
= ONLY AVAILABLE WITH BODY
HEIGHT -05.0 AND -10 ROW.
SOLDER COMPOSITION & STYLE
****
= 10 POSITION ONLY AVAILABLE
-1: 63% TIN / 37% LEAD
IN 4 ROW
CHARGE TAIL
*****=ONLY
AVAILABLE WITH -06.5
(USE SUB-C-209-XX.X-S-1)
LEAD STYLE AND -06 ROW.
-2:
95.5% TIN / 3.8% SILVER /
=ONLY AVAILABLE WITH -06.5
.7% COPPER CHARGE TAIL
LEAD STYLE AND -04 ROW
=ONLY AVAILABLE WITH 30 POS & 4 ROW (USE SUB-C-209-XX.X-S-2)
.050 1.27 (TYP)
* = NOT TOOLED
C
(No OF POS - 1) x .0500[1.270] (TYP)
.035±.005 0.89±0.13
(TYP)
C
C
L
.017 0.42
(REF)
.016±.003 0.40±0.08
.056±.003 1.42±0.08 (TYP)
C
C
'T'
SUB-C-209-XX.X-X-X
.044 1.12 (TYP)
.050 1.27 REF (TYP)
C
L
C
L
SOLDER CHARGE
DETAIL 'T'
SCALE 8 : 1
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: .75 LBS.
3. NOTE DELETED.
4. 5 ROW SOLDER TAILS ARE NOT SYMMETRICAL WITH BODY
WIDTH (DIM .321[8.15]); SEE FIG. 6, SHEET 3).
5. INSPECT DIMENSION AT 4 CORNERS OF PART.
6. WITHOUT -A AVAILABLE FOR EXISTING CUSTOMERS ONLY AS OF REVISION Y.
7. POLYIMIDE PAD WILL BE SUPPLIED WHETHER OR NOT -K IS SPECIFIED.
8. TAPE & REEL WILL BE SUPPLIED WHETHER OR NOT -TR IS SPECIFIED.
9. FOR QUANTITIES UP TO 49 PIECES, NO LEADER, TRAILER, OR REEL WILL BE SUPPLIED.
FOR QUANTITIES OF 50 - 124 PIECES, NO LEADER OR TRAILER WILL BE SUPPLIED.
10. ATTACH LABEL "SEAX-0001" TO EACH TAPE & REEL PACKAGE.
11. SEE RECOMMENDED FOOTPRINT DRAWING FOR STENCIL REQUIREMENTS.
12. SOLDER CHARGE VOLUME IS .891 x 10^-5 IN ^3 REF.
SECTION "A"-"A"
SCALE 4 : 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
INSULATOR: LCP, COLOR: BLACK
CONTACT OR TERMINAL: COPPER ALLOY
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050 PITCH SOCKET ARRAY ASSEMBLY
SHEET
1
OF
6
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
F:\DWG\MISC\MKTG\SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR-MKT.SLDDRW
BY:
BRATCHER 05/27/2004
REVISION AJ
.225 5.72 REF
-10: 10 ROW
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(SEAF-30-05.0-XX-10-1-A-XX-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
C
L
10
FIG. 2
.100 2.54
REF (TYP)
"E"
(SEE NOTE 5)
C
.004 0.10
(SEE NOTE 5)
C
SEE TABLE 4
.461 11.71
REF
C
L
.300 7.62
REF
DETAIL 'B'
SCALE 7 : 1
.521 13.23
REF
01
.172 4.37 REF
SEAF-XX-XX.X-10
AH
-A: ALIGNMENT PINS
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(SEAF-30-05.0-XX-08-1-A-XX-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
FIG. 3
.040 1.02
REF
.050 1.27
REF (TYP)
-K: POLYIMIDE PAD
(SEAF-30-05.0-XX-08-1-A-XX-K-TR SHOWN)
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(ALL CONTACTS NOT SHOWN FOR CLARITY)
(HAND PLACE USE K-850-650)
DOT APPLICATOR-KAPTON TAPE: USE
-04 ROW: K-DOT-.138-.250-.005
-05/-06 ROW: K-DOT-.236-.343-.005
-08 ROW: K-DOT-.325-.450-.005
-10 ROW: K-DOT-.404-.500-.005
C
L
FIG. 4
"D" .020[0.51]
.044 1.12 REF
(No OF POS x .050[1.27]) + .141[3.58] REF
C
L
SEAF-XX-XX.X-XX-A
'E'
"F"
REF
"C" .020[0.51]
"B"
C
L
PROPRIETARY NOTE
.034 0.86
REF
.044 1.12
REF .034 0.86
REF
.044 1.12
REF
DETAIL 'E'
SCALE 6 : 1
DETAIL 'E'
ALTERNATE
CONSTRUCTION
SCALE 6:1
F:\DWG\MISC\MKTG\SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR-MKT.SLDDRW
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050 PITCH SOCKET ARRAY ASSEMBLY
SHEET
2
OF
6
BY:
BRATCHER 05/27/2004
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
REVISION AJ
.040 1.02 REF
.028 0.71 REF
C
L
06
.029 0.72 REF
.050 1.27
REF (TYP)
-06: 6 ROW
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(SEAF-20-05.0-XX-06-1-A-XX-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
FIG. 5
.261 6.63
REF
C
L
.100 2.54 REF
.323 8.20
REF
SEAF-XX-XX.X-06-X
-01
.172 4.37 REF
.028 0.71 REF
C
L
05
.050 1.27
REF (TYP)
-05: 5 ROW
(SAME AS FIG. 5, EXCEPT AS SHOWN)
(SEAF-20-05.0-XX-05-1-A-XX-K-TR SHOWN)
(POLYIMIDE NOT SHOWN FOR CLARITY)
FIG. 6
C
L
.100 2.54 REF
.261 6.63
REF
SEAF-XX-XX.X-05-X
01
.172 4.37 REF
.321 8.15 REF
(SEE NOTE 4)
"F"
"F"
.128 3.25
(SEE NOTE 4)
.072 1.83
(SEE NOTE 4)
SECTION "F"-"F"
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.333333
.050 PITCH SOCKET ARRAY ASSEMBLY
SHEET
3
OF
6
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
F:\DWG\MISC\MKTG\SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR-MKT.SLDDRW
BY:
BRATCHER 05/27/2004
REVISION AJ
**-N: NOTCH OPTION
(SAME AS FIG. 3, EXCEPT AS SHOWN)
(SEAF-30-05.0-XX-06-1-A-N-K-TR SHOWN)
(-05.0 LEAD STYLE ONLY)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
**
= NOT RELEASE PRODUCTION
FIG.7
1.795 45.59
REF
"G"
"G"
.040 1.02
REF
.130 3.30
REF
.033 0.84
REF
.224 5.69
REF
SECTION "G"-"G"
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050 PITCH SOCKET ARRAY ASSEMBLY
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
SHEET
4
OF
6
F:\DWG\MISC\MKTG\SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR-MKT.SLDDRW
BY:
BRATCHER 05/27/2004
REVISION AJ
-04: 4 ROW
(SEAF-20-05.0-XX-04-1-A-XX-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
(SAME AS FIG.1 EXCEPT AS SHOWN )
.026 0.66
REF
.066 1.68
REF
FIG. 12
.221 5.61
REF
.076 1.93
REF
.100 2.54
REF
04
.074 1.88
REF
C
L
.035 0.89
REF
.161 4.09
REF
.170 4.32
REF
.076 1.93
REF
01
.046 1.17
REF
.053 1.35 REF
.050 1.27
REF (TYP)
.179 4.55
REF
.199 5.05
REF
SEAF-XX-05.0-XX-A-LP
.140 3.56
REF
C
L
C
L
.117 2.97
(TYP) REF
.321 8.15
REF
(No OF POS x .050[1.27] + .762[19.35] REF
(No OF POS x .050[1.27] + .533[13.54]
- .010
+.005
.221 5.61
REF
WT-43-01-T
.610 15.49
REF
-LP OPTION
(SEAF-30-05.0-XX-06-1-A-LP-K-TR SHOWN)
(ALL CONTACTS, POLYIMIDE NOT SHOWN FOR CLARITY)
(SAME AS FIG.12 EXCEPT AS SHOWN )
(-LP OPTION REQUIRED FOR SEAC MATE ONLY)
(ONLY AVAILABLE WITH -O5.O LEAD STYLE 6, & 8 ROW)
PROPRIETARY NOTE
FIG. 13
.186 4.72 (TYP)
REF
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
.070 1.78
DO NOT SCALE DRAWING
(No OF POS x .050[1.27] + .416[10.57]±.005
.117 2.97
(TYP) REF
F:\DWG\MISC\MKTG\SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR-MKT.SLDDRW
.050 PITCH SOCKET ARRAY ASSEMBLY
SHEET
5
OF
6
SHEET SCALE: 1:0.333333
BY:
BRATCHER 05/27/2004
SEAF-XX-XX.X-XX-XX-X-A-XX-K-TR
