T-1 3/4 (5mm) SOLID STATE LAMPS
L7113H BRIGHT RED
L7113I HIGH EFFICIENCY RED
L7113N PURE ORANGE
L7113PG PURE GREEN
L7113G GREEN
L7113E ORANGE
L7113Y YELLOW
Features
HIGH INTENSITY.
LOW POWER CONSUMPTION.
POPULAR T-1 DIAMETER PACKAGE.
GENERAL PURPOSE LEADS.
RELIABLE AND RUGGED.
LONG LIFE - SOLID STATE RELIABILITY.
AVAILABLE ON TAPE AND REEL.
Description
The Bright Red source color devices are made with Gallium
Phosphide Red Light Emitting Diode.
The High Efficiency Red and Orange source color devices are
made with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium Arsenide
Phosphide on Gallium Phosphide Yellow Light Emitting Diode.
The Pure Orange source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Pure Orange
Light Emitting Diode.
The Pure Green source color devices are made with Gallium
Phosphide Pure Green Light Emitting Diode.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
SPEC NO: DSAA0189
REV NO: V.1
DATE: MAR/13/2001
PAGE: 1 OF 6
Selection Guide
Part No.
L7113HD
L7113ID
L7113IT
L7113EC
L7113ED
L7113GD
L7113GT
L7113GC
L7113YD
L7113YT
L7113YC
L7113ND
L7113NT
L7113NC
L7113PGD
L7113PGT
L7113PGC
PURE GREEN (GaP)
PURE ORANGE (GaAsP/GaP)
YELLOW (GaAsP/GaP)
GREEN (GaP)
ORANGE (GaAsP/GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
Dice
BRIGHT RED (GaP)
Lens Type
RED DIFFUSED
RED DIFFUSED
RED TRANS.
WATER CLEAR
ORANGE DIFFUSED
GREEN DIFFUSED
GREEN TRANS.
WATER CLEAR
YELLOW DIFFUSED
YELLOW TRANS.
WATER CLEAR
ORANGE DIFFUSED
ORANGE TRANS.
WATER CLEAR
GREEN DIFFUSED
GREEN TRANS.
WATER CLEAR
2
12
50
50
12
5
20
20
5
20
20
12
50
50
2
5
5
Iv (mcd)
@ 10 mA
Min.
Typ.
5
30
80
80
30
20
50
50
20
40
40
30
80
80
5
10
10
Viewing
Angle
2θ1/2
30°
30°
20°
20°
30°
30°
20°
20°
30°
20°
20°
30°
20°
20°
30°
20°
20°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par ameter
Dev ic e
Bright Red
High Efficiency Red
Orange
Green
Yellow
Pure Orange
Pure Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Pure Orange
Pure Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Pure Orange
Pure Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Pure Orange
Pure Green
All
Ty p .
700
625
625
565
590
610
555
45
45
45
30
35
35
30
40
12
12
45
10
15
45
2.0
2.0
2.0
2.2
2.1
2.0
2.25
10
2.5
2.5
2.5
2.5
2.5
2.6
2.6
Max .
Un i t s
Tes t Co n d itio n s
λ
peak
Peak Wavelength
nm
IF=20mA
∆λ
1/2
Spectral Line
Halfwidth
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
VR = 5V
SPEC NO: DSAA0189
REV NO: V.1
DATE: MAR/13/2001
PAGE: 2 OF 6
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
B r ig h t
Red
120
25
150
5
Hi g h
Effic ien c y
Red
105
30
150
5
Or an g e
105
30
150
5
Gr een
105
25
150
5
Yello w
105
30
150
5
Pu r e
Or an g e
105
30
150
5
Pu r e
Gr een
105
25
150
5
Un i t s
mW
mA
mA
V
-40
°
C To +85
°C
260
°
C For 5 Seconds
SPEC NO: DSAA0189
REV NO: V.1
DATE: MAR/13/2001
PAGE: 3 OF 6
Green L7113GD,L7113GC,L7113GT
Yellow L7113YD,L7113YC,L7113YT
SPEC NO: DSAA0189
REV NO: V.1
DATE: MAR/13/2001
PAGE: 5 OF 6
