7-1437580-4: DescriptionSLIDE SWITCH, 4P4T, LATCHED, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT; CategoryMechanical and electronic products switch; File Size118KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

7-1437580-4 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	7-1437580-4	-	-	View	Buy Now

7-1437580-4 Overview

SLIDE SWITCH, 4P4T, LATCHED, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT

7-1437580-4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	compliant
ECCN code	EAR99
Actuator type	EXTENDED TOP TYPE
Contact (AC) maximum rated R load	.02A@20VAC
Maximum contact current (AC)	0.02 A
Maximum contact current (DC)	0.02 A
Contact (DC) maximum rated R load	.02A@20VDC
Maximum contact voltage (AC)	20 V
Maximum contact voltage (DC)	20 V
Installation features	THROUGH HOLE-STRAIGHT
surface mount	NO
Switch action	LATCHED
switch function	4P4T
Switch type	SLIDE SWITCH
Termination type	SOLDER

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

MSSA4450G Product Details

Live Product Chat

Slide Switches

5 of 6 EU R oHS/ELV C om plia nt

(

Find R oHS C om plia nt

Alte rna te s

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

MSSA4450G

(7-1437580-4)

T E I nternal N umber: 7 - 1 4 3 7 5 8 0 - 4

Product Highlights:

4 Positions

Four Pole - Four Throw C onfiguration (Pole-Throw)

Actuator Style = Extended, Top

Actuator C olor = Black

MSSA Series

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Number of Positions

= 4

C onfiguration (Pole-Throw) = Four Pole - Four Throw

Actuator Style = Extended, Top

Mount Angle = Vertical

Terminal C onfiguration = Standard

Grade = Instrumentation

Termination Type = PC

PC B Retention Feature = Yes

Electrical Characteristics:

C ontact Rating = 0.4 VA max @ 20 VDC or peak AC

Body Related Features:

Actuator C olor = Black

Series = MSSA

Mount Style = Through-Hole

PC B Tail Length (mm [in]) = 3.51 [0.136]

PC B Retention Method = Guide Posts

Actuator Length (mm [in]) = 10.40 [0.410]

Actuator Material = Polyester

Flammability Rating = UL 94V-0

Actuator Travel = 2.50 [.098]

Contact Related Features:

C ontact Plating = Gold

Configuration Related Features:

Number of Actuators = Single

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

Identification Marking:

Stamped Marking = With

Other:

Brand = Alcoswitch

Additional Information:

Product Line Information

7-1437580-4 Related Products

	7-1437580-4	MSSA4450G
Description	SLIDE SWITCH, 4P4T, LATCHED, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT	SLIDE SWITCH, 4P4T, LATCHED, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT
Is it lead-free?	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible
Maker	TE Connectivity	TE Connectivity
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
Actuator type	EXTENDED TOP TYPE	EXTENDED TOP TYPE
Contact (AC) maximum rated R load	.02A@20VAC	.02A@20VAC
Maximum contact current (AC)	0.02 A	0.02 A
Maximum contact current (DC)	0.02 A	0.02 A
Contact (DC) maximum rated R load	.02A@20VDC	.02A@20VDC
Maximum contact voltage (AC)	20 V	20 V
Maximum contact voltage (DC)	20 V	20 V
Installation features	THROUGH HOLE-STRAIGHT	THROUGH HOLE-STRAIGHT
surface mount	NO	NO
Switch action	LATCHED	LATCHED
switch function	4P4T	4P4T
Switch type	SLIDE SWITCH	SLIDE SWITCH
Termination type	SOLDER	SOLDER
