Following the above format, Saronix-eCera part numbers will be assigned upon
confirmation of exact customer requirements.
Legacy Ordering Information - For Reference Only:
S EL381 3 B - 622.0800 (T)
SaRonix
Product Series
Output Enable/Disable Function
0 = N/C pin 1, N/C pin 2
1 = OE low true pin 1, N/C pin2
2 = N/C pin 1, OE low true pin2
3 = OE high true pin 1, N/C pin 2
4 = N/C pin 1, OE high true pin2
Packaging
(T) = Tape & Reel
full reel increments
Blank = Bulk packaged
Output Frequency
(MHz)
Frequency Stability
AA = ±20 ppm (0 to +70°C)
A = ±25 ppm (0 to +70°C)
B = ±50 ppm (0 to +70°C)
E = ±50 ppm (-40 to +85°C)
H = ±32 ppm (-40 to +85°C)
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-435-0800 TW: +886-3-4518888
•
www.saronix-ecera.com
All specifications are subject to change without notice.
PN 3.3V REV2008_DEC04_01.6
1
3.3V PECL
Low Jitter XO
PN
PN Series Crystal Clock Oscillator (XO)
Legacy SEL381 Series | 7.0 x 5.0mm
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output Frequency
Supply Voltage
Supply Current
Frequency Stability
Operating Temp. Range
Output Logic 0, V
OL
Output Logic 1, V
OH
Output Load
Duty Cycle
Rise and Fall Time
Jitter, Phase
Jitter, Accumulated
Jitter, Total
1
2.97
3.3
800
3.63
25
65
100
±20 to ±50
MHz
V
mA
mA
mA
ppm
°C
V
V
As specified
<24 MHz
24 to 96 MHz
96 to 800 MHz
See Note 1 below
As specified
-40 to +85°C
-40 to +85°C
output requires termination
measured at V
DD
- 1.3 VDC
measured 20/80% of waveform
12kHz to 20MHz frequency band
10,000 adjacent periods
10,000 random periods
100 Hz offset (155.52 MHz output)
1 kHz offset (155.52 MHz output)
10 kHz offset (155.52 MHz output)
100 kHz offset (155.52 MHz output)
-40
V
CC
– 1.025
50Ω to V
CC
– 2V
45
0.5
2.5
+85
V
CC
– 1.620
55
1.5
4
6
40
–90
–115
–125
–119
%
ns
ps RMS (1-σ)
ps RMS (1-σ)
ps pk-pk
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
Phase Noise
Notes:
1.
2.
As specified. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance
(25°C), aging (5 years at 40°C average effective ambient temperature), shock and vibration.
For specifications other than those listed, please contact sales
Output Enable / Disable Function (Active High Default and Active Low*)
Parameter
Min.
Typ.
Max.
Units
Notes
Input Voltage (pin OE), Output Enable
Input voltage (pin OE), Output Disable
*Input Voltage (OE pin), Output Enable
*Input voltage (OE pin), Output Disable
*Note:
1.
Oe active low option is available. Please contact sales.
V
OH
V
OL
V
OL
V
OH
V
V
V
V
or open (Legacy SEL3813 and SEL3814)
Outputs disabled to Hi-Z
or open (Legacy SEL3811 and SEL3812)
Outputs disabled to Hi-Z
Absolute Maximum Ratings
Parameter
Min.
Typ.
Max.
Units
Notes
Storage Temperature
-55
+125
°C
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-435-0800 TW: +886-3-4518888
•
www.saronix-ecera.com
All specifications are subject to change without notice.
PN 3.3V REV2008_DEC04_01.6
2
3.3V PECL
Low Jitter XO
PN
PN Series Crystal Clock Oscillator (XO)
Legacy SEL381 Series | 7.0 x 5.0mm
Test Circuit
+2V
Test Point
(Termination
internal to scope)
0.1μF
0.01μF
6
1
5
2
4
3
50
50
-1.3V
0.1μF
0.01μF
Output Enable/Disable Function
(OE function present on specified pin)
Reflow Soldering Profile
As per IPC/JEDEC J-STD-020C
1 to 3°C/sec max
Temperature – °C
260
Peak 260°C for 10 sec max
1 to 3°C/sec
217
Time
60 to 90 sec
4 to 6 minutes max
Reliability Test Ratings
Type
This product is rated to meet the following test conditions:
