• ZENER DIODE CHIPS
• ALL JUNCTIONS COMPLETELY PROTECTED WITH SILICON DIOXIDE
• ELECTRICALLY EQUIVALENT TO 1N5333B THRU 1N5379B
• 5 WATT CAPABILITY WITH PROPER HEAT SINKING
• COMPATIBLE WITH ALL WIRE BONDING AND DIE ATTACH TECHNIQUES,
WITH THE EXCEPTION OF SOLDER REFLOW
CD5333B
thru
CD5379B
ELECTRICAL CHARACTERISTICS
@ 25°C, unless otherwise specified
58 MILS
NOMINAL
ZENER
VOLTAGE
VZ
(Note 1)
V
CD5333B
CD5334B
CD5335B
CD5336B
CD5337B
CD5338B
CD5339B
CD5340B
CD5341B
CD5342B
CD5343B
CD5344B
CD5345B
CD5346B
CD5347B
CD5348B
CD5349B
CD5350B
CD5351B
CD5352B
CD5353B
CD5354B
CD5355B
CD5356B
CD5357B
CD5358B
CD5359B
CD5360B
CD5361B
CD5362B
CD5363B
CD5364B
CD5365B
CD5366B
CD5367B
CD5368B
CD5369B
CD5370B
CD5371B
CD5372B
CD5373B
CD5374B
CD5375B
CD5376B
CD5377B
CD5378B
CD5379B
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.0
6.2
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
28
30
33
36
39
43
47
51
56
60
62
68
75
82
87
91
100
110
MAXIMUM
ZENER
IMPEDANCE
ZZT
(Note 2)
OHMS
3.0
2.5
2.0
2.0
2.0
1.5
1.0
1.0
1.0
1.0
1.5
1.5
2.0
2.0
2.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
3.0
3.0
3.5
3.5
4.0
5.0
6.0
8.0
10
11
14
20
25
27
35
40
42
44
45
65
75
75
90
125
MAXIMUM
ZENER KNEE
IMPEDANCE
ZZK @ 1.0 mA
(Note 2)
OHMS
400
500
500
500
450
400
400
300
200
200
200
200
200
150
125
125
125
100
75
75
75
75
75
75
75
75
100
110
120
130
140
150
160
170
190
210
230
280
350
400
500
620
720
760
760
800
1000
64 MILS
TYPE
NUMBER
mA
380
350
320
290
260
240
220
200
200
175
175
150
150
150
125
125
100
100
100
75
75
70
65
65
65
50
50
50
50
50
40
40
30
30
30
25
25
20
20
20
20
20
15
15
15
12
12
µ
A
300
150
50
10
5.0
1.0
1.0
1.0
1.0
10
10
10
10
7.5
5.0
5.0
2.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0L5
0.5
0.5
0.5
0.5
0.5
0.5
VOLTS
1.0
1.0
1.0
1.0
1.0
1.0
2.0
3.0
3.0
5.2
5.7
6.2
6.6
6.9
7.6
8.4
9.1
9.9
10.6
11.5
12.2
12.9
13.7
14.4
15.2
16.7
18.2
19
20.6
21.2
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
45.5
47.1
51.7
56
62.2
66
69.2
76
83.6
BACKSIDE IS CATHODE
FIGURE 1
DESIGN DATA
METALLIZATION:
Top: (Anode)....................Al
Back: (Cathode).......... ...Au
AL THICKNESS.......
....25,000
Å
Min
GOLD THICKNESS........4,000
Å
Min
CHIP THICKNESS.............
.....10 Mils
CIRCUIT LAYOUT DATA:
For Zener operation, cathode
must be operated positive with
respect to anode.
TOLERANCES:
ALL
Dimensions + 2 mils
NOTES ON PAGE 162
22 COREY STREET, MELROSE, MASSACHUSETTS 02176
PHONE (781) 665-1071
FAX (781) 665-7379
WEBSITE: http://www.cdi-diodes.com
E-mail: mail@cdi-diodes.com
58 MILS
64 MILS
TEST
CURRENT
lZT
MAXIMUM REVERSE
CURRENT
lR @ VR
CD5333B thru CD5379B
100
50
20
ZENER IMPEDANCE ZZT (OHMS)
MAXIMUM RATINGS
Operating Temperature: -65°C to +200°C
Storage Temperature: -65°C to +200°C
Forward Voltage @ 1.0Amp = 1.5 Volts maximum
10
5
2
1
.5
.2
1
2
5
10
20
50
100
200
OPERATING CURRENT lZT (mA)
500
1000
FIGURE 2
ZENER IMPEDANCE VS. OPERATING CURRENT
1000
500
400
300
200
ZENER IMPEDANCE ZZT (OHMS)
100
50
40
30
20
10
5
4
3
2
1
2
5
10
20
50
100
200
500
1000
OPERATING CURRENT lZT (mA)
FIGURE 3
ZENER IMPEDANCE VS. OPERATING CURRENT
NOTE 1
Zener voltage range equals nominal voltage + 5% for “B” Suffix. “A” Suffix denotes + 10%. No Suffix denotes + 20%.
"C" suffix = + 2% and "D" suffix = + 1%.
NOTE 2
Zener impedance is derived by superimposing on lZT and lZK, A 60 Hz rms a.c. current equal to 10% of lZT and lZK.
NOTE 3
Zener voltage is read using a pulse measurement, 10 milliseconds maximum.
