SMT COMMON MODE INDUCTORS
0.5A to 3.6A
Pick and place compatible
Rated voltage 250V
AC
Low RFI toroid
Tape & Reel packaging available
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
3
Part
1,2
Number
PE-53914NL
PE-53913NL
PE-53912NL
PE-53911NL
PE-53910NL
Inductance
(mH MIN)
13.2
6.0
1.8
0.9
0.6
Irated
(A)
0.50
1.00
2.50
1.50
3.60
DCR (MAX)
(mΩ)
850
450
80
60
50
Typical
SRF
(MHz)
0.3
0.5
2.2
2
4
Impedance
Curve
5
4
3
2
1
Size
Code
LCCI-37
LCCI-37
LCCI-50
LCCI-37
LCCI-50
Weight
(Grams)
2.4
2.4
5.2
2.5
5.3
Quantity
In Tube
30
30
30
30
30
NOTE:
1. Optional Tape & Reel packaging can be ordered by adding a "T"
suffix to the part number (i.e. PE-53914L becomes PE-53914LT).
Pulse complies to industry standard tape and reel specification
EIA481.
2. The "NL" suffix indicates an RoHS-compliant part number. Non-NL
suffixed parts are not necessarily RoHS compliant, but are electri
cally and mechanically equivalent to NL versions. If a part number
does not have the "NL" suffix, but an RoHS compliant version is
required, please contact Pulse for availability.
3. The temperature of the component (ambient plus temperature rise)
must be within the stated operating temperature range.
Mechanical
E± .005
0,13
R
4X .060
1,52
A
MAX
Schematic
1
4
1:1 ±2%
2
3
4X
.175
4,45
2
F±
.005
0,13
1
Typical Impedance Curves
3
4
Impedance
(Ω)
7K
6K
5K
4K
3K
2K
1K
0
2
1
5
4
3
SUGGESTED PAD LAYOUT
C
MAX
D± .015
0,38
B MAX
.005/0,13
4 SURFACES
0
0.01
0.1
1
10
100
Frequency (MHz)
Size
LCCI-37
LCCI-50
A
.560/14,22
.670/17,02
B
.645/16,38
.770/19,56
C
.350/8,89
.390/9,90
D
.520/13,21
.650/16,51
E
.340/8,64
.445/11,30
F
.530/13,46
.660/16,76
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
115
SPM2007 (11/07)
