Cross Reference Guide
PN5352 / SPN5352*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
10.0 - 300.0 MHz
17.0 dB Typical
16.0 dB Min
3.5 dB Typical
3.8 dB Max
20.0 dBm Typical
17.5 dBm Min
33.0 dBm Typical
47.0 dBm Typical
1.8/2.0 Input Typ/Max
1.5/2.0 Output Typ/Max
-20.0 dB Typical
-19.0 dB Min
12.0 Volts
55.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
10.0
50.0
100.0
200.0
300.0
0.160
0.040
0.070
0.150
0.240
-76.00
-87.00
-94.00
-123.00
-159.00
6.840
7.190
7.150
7.160
7.210
-156.00
166.00
148.00
114.00
80.00
0.090
0.090
0.090
0.100
0.110
-155.00
163.00
145.00
108.00
75.00
0.150
0.080
0.120
0.180
0.180
-33.00
20.00
23.00
3.00
-30.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.2 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
