5646245-4 Product Details
Live Product Chat
.100 Centerline Stripline Connectors (Z-PACK SL 100)
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5646245-4
T E I nternal N umber: 5 6 4 6 2 4 5 - 4
Product Highlights:
l
C onnector Type = Plug
l
PC B Mount Angle = Vertical
l
180 Positions
l
Body Style = Discretely Molded
l
Lead Length = 3.68 mm
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onnector Type = Plug
l
PC B Mount Angle = Vertical
l
Number of Positions
= 180
l
Body Style
= Discretely Molded
l
PC B Retention Feature
= No
l
C omment = Solder leads require a drilled hole diameter of 0.61?
0.20, -0.05 [.024?.008,-.002]
Mechanical Attachment:
l
Lead Length (mm [in])
= 3.68 [0.145]
l
Stiffener Material = Aluminum
Termination Related Features:
l
Solder Tail C ontact Plating = Tin over Nickel
Contact Related Features:
l
C ontact Plating, Mating Area, Material = Gold Flash over Palladium
Nickel
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
l
Housing C olor = Black
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
