DUAL-IN-LINE
SOCKETS
SERIES 210, 222, 223 • SOLDER TAIL AND WRAPOST • CLOSED FRAME
0,38-0,64
0,25
*
0,46
B
•
Closed frame insulator withstands high
mechanical impact
3-level wraposts
•
Available with standard solder pins, 2-level or
2,79
4,19
4,9
3,71
2,41
•
Hi-Rel, 4-finger BeCu #30 contact is rated at
3 amps. See page 253 for details
3,18
L=9,4
OR
L=12,96
•
Series 210, 222 and 223 use MM #1001, #0088
or #0089 pins. See pages 165 & 198 for details
suitable for all soldering operations
Data, see page 264 for details
0,51 DIA.
0,64
SQUARE
•
Insulators are high temperature thermoplastic,
•
For Electrical, Mechanical and Environmental
See page 131 for Insulator Details
Total number
of pins
A
B
2,54
C
Quantity
per tube
ORDERING INFORMATION
Solder Tail
210-XX-306-41-001000
210-XX-308-41-001000
210-XX-310-41-001000
210-XX-314-41-001000
210-XX-316-41-001000
210-XX-318-41-001000
210-XX-320-41-001000
210-XX-322-41-001000
210-XX-324-41-001000
210-XX-422-41-001000
210-XX-424-41-001000
210-XX-624-41-001000
210-XX-628-41-001000
210-XX-632-41-001000
210-XX-636-41-001000
210-XX-640-41-001000
210-XX-964-41-001000
(2 Level Wrapost)
222-XX-306-41-001000
222-XX-308-41-001000
222-XX-310-41-001000
222-XX-314-41-001000
222-XX-316-41-001000
222-XX-318-41-001000
222-XX-320-41-001000
222-XX-322-41-001000
222-XX-324-41-001000
222-XX-422-41-001000
222-XX-424-41-001000
222-XX-624-41-001000
222-XX-628-41-001000
222-XX-632-41-001000
222-XX-636-41-001000
222-XX-640-41-001000
222-XX-964-41-001000
A
7,6
10,1
12,6
17,7
20,3
22,8
25,3
27,8
30,4
27,8
30,4
30,4
35,5
40,6
45,7
50,8
81,2
B
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
10,16
10,16
15,24
15,24
15,24
15,24
15,24
22,86
C
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
12,7
12,7
17,7
17,7
17,7
17,7
17,7
25,3
L = 9,4
(3 Level Wrapost)
223-XX-306-41-001000
223-XX-308-41-001000
223-XX-310-41-001000
223-XX-314-41-001000
223-XX-316-41-001000
223-XX-318-41-001000
223-XX-320-41-001000
223-XX-322-41-001000
223-XX-324-41-001000
223-XX-422-41-001000
223-XX-424-41-001000
223-XX-624-41-001000
223-XX-628-41-001000
223-XX-632-41-001000
223-XX-636-41-001000
223-XX-640-41-001000
223-XX-964-41-001000
L = 12,96
6
8
10
14
16
18
20
22
24
22
24
24
28
32
36
40
64
67
50
40
28
25
22
20
18
16
18
16
16
14
12
11
10
6
XX=Plating Code
See Below
2011/65/EU
RoHS - 2
SPECIFY PLATING CODE XX =
Sleeve
(Pin)
Contact
(Clip)
11
0,25μm
Au
0,25μm
Au
13
0,25μm
Au
0,76μm
Au
91
0,25μm
Au
93
0,76μm
Au
99
2,54μm
Sn/Pb
41
5,08μm
Sn
0,25μm
Au
43
5,08μm
Sn
0,76μm
Au
44
5,08μm
Sn
2,54μm
Sn
5,08μm
Sn/Pb
5,08μm
Sn/Pb
5,08μm
Sn/Pb
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 99 | IC SOCKETS / TO SOCKETS
