DEW1021 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> DEW1021

DEW1021: DescriptionDC-DC Regulated Power Supply Module, PLASTIC, SIP-7/9; CategoryPower/power management The power supply circuit; File Size286KB，8 Pages; ManufacturerDelta Electronics

Download Datasheet Parametric View All

DEW1021 Overview

DC-DC Regulated Power Supply Module, PLASTIC, SIP-7/9

DEW1021 Parametric

Parameter Name	Attribute value
Maker	Delta Electronics
Parts packaging code	MODULE
package instruction	PLASTIC, SIP-7/9
Contacts	7/9
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
JESD-30 code	R-XSMA-T7
Number of terminals	7
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

Preview

Download Datasheet

View All

FEATURES

Efficiency up to 80%

Industry standard form factor and pinout

Body size:

25.95 x9.25 x12.45mm

(1.02” x0.36” x0.49”)

Input: 5V, 12V, 24V, 48V (2:1)

Output: 3.3, 5, 12, 15,

±5, ±12, ±15V

Output OCP, SCP

Low ripple and noise

1500V isolation

UL 94V-0 Package Material

ISO 9001 and ISO14001 certified

manufacturing facility

Delphi DEW1000 Series DC/DC Power

Modules: 24, 48Vin, 2W SIP

The Delphi DEW1000, 24V and 48V 4:1 wide input, single or dual

output, DIP form factor, isolated DC/DC converter is the latest

offering from a world leader in power systems technology and

manufacturing

―

Delta Electronics, Inc. The DEW1000 series

operate from 24V or 48V (4:1) and provides 3.3V, 5V, 12V, or 15V of

single output or

5V,

12V, or

15V of dual output in an industrial

standard, plastic case encapsulated SIP package. This series

provides up to 2W of output power with 1500V isolation and a typical

full-load efficiency up to 80%. With creative design technology and

optimization of component placement, these converters possess

outstanding electrical and thermal performance, as well as extremely

high reliability under highly stressful operating conditions.

OPTIONS

APPLICATIONS

Industrial

Transportation

Process/ Automation

Telecom

Data Networking

DATASHEET

DS_DEW1000_12032008
