2-440397-2 Product Details
Live Product Chat
Stacked Connectors
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
No Im a ge Ava ila ble
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
2-440397-2
T E I nternal N umber: 2 - 4 4 0 3 9 7 - 2
Obsolete
C ontact Product Information
C enter
Product Highlights:
l
C onnector C onfiguration [Upper C onn./Lower C onn.] =
Same Series
l
Receptacle over Receptacle
l
Mating C onnector Lock Type = Threaded Insert, 4-40
UNC
l
Without Mating Polarization
l
Yes PC B Retention Feature
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
AMPLIMITE SUBMINATURE D TYPE C ONNEC TORS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version C )
l
3D Model
(IGES, Version C )
l
3D Model
(STEP, Version C )
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Gender
= Receptacle over Receptacle
l
Mating C onnector Lock Type = Threaded Insert, 4-40 UNC
l
Mating Polarization = Without
l
PC B Retention Feature
= Yes
l
Stacked Number of Positions [Upper C onn./Lower C onn.]
= 25/25
l
Stacked Shell Size [Upper C onn./Lower C onn.]
= 3/3
l
Shell Type = Front Metal Shell
l
Product Series = Series II
l
C olor C ode = None
l
PC B Mount Angle = Right Angle
l
Stacked Product Series [Upper C onn./Lower/ C onn.] = HD-20 / HD-
20
Body Related Features:
l
C onnector C onfiguration [Upper C onn./Lower C onn.]
= Same Series
l
C enterline, Matrix (mm [in])
= 2.77 x 2.84 [.109 x .112]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (10)
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing C olor = Black
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
