CX1HSM CRYSTAL
10 kHz to 600 kHz
Miniature Surface Mount
Quartz Crystal for Series Oscillators
DESCRIPTION
The CX1HSM quartz crystal is a high quality tuning fork
resonator for use in Series (two cascaded inverters)
oscillators. The CX1HSM is hermetically sealed in a rugged,
miniature ceramic package. The CX1HSM crystal is
manufactured using the STATEK-developed photo-
lithographic process, and was designed utilizing the
experience acquired by producing millions of crystals for
industrial, commercial, military and medical applications.
Maximum process temperature should not exceed 260
O
C.
FEATURES
Actual size
Side view
Glass Lid Shown
PACKAGE DIMENSIONS
Miniature tuning fork design
High shock resistance
Designed for low power applications
Compatible with hybrid or PC board packaging
Low aging
Full military testing available
Designed and manufactured in the USA
DIM
A
B
C
D
EQUIVALENT CIRCUIT
TYP.
inches
0.315
0.140
-
0.045
0.060
mm
8.00
3.56
-
1.14
1.52
inches
0.330
0.155
0.055
0.070
MAX.
mm
8.38
3.94
1.40
1.78
see below
E
DIM “C”
MAX
SM1
SM2/SM4
SM3/SM5
GLASS LID
inches
0.065
0.067
0.070
mm
1.65
1.70
1.78
CERAMIC LID
inches
0.070
0.072
0.075
mm
1.78
1.83
1.90
CONVENTIONAL SERIES
OSCILLATOR CIRCUIT
SUGGESTED LAND PATTERN
10122 - Rev E
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
SPECIFICATIONS
FIGURE 1
CX1H TYPICAL MOTIONAL RESISTANCE (R
1
)
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice.
Frequency Range
10 kHz to 600 kHz
Standard Calibration Tolerance
1
(see table below)
Motional Resistance (R
1
)
Figure 1
MAX.: 10-169.9 kHz, 2x Typ.
170-600 kHz, 2.5x Typ.
Motional Capacitance (C
1
) Figure 2
Quality Factor (Q)
Figure 3
Min. is 0.25x Typ.
Shunt Capacitance (C
0
)
2.0 pF MAX
Drive Level
10-24.9 kHz 1.5
µW
MAX
25-600 kHz 3.0
µW
MAX
Turning Point (T )
2
Figure 4
0
Temperature Coefficient (k) -0.035 ppm/
O
C
2
Aging, first year
5 ppm MAX
Shock, survival
3
1,000 g, 1ms,
1
/
2
sine
Vibration, survival
3
20 g RMS, 10-2,000 Hz
Operating Temp. Range
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
Storage Temp. Range
-55
O
C to +125
O
C
Max Process Temperature 260
O
C for 20 sec.
1. Tighter frequency calibration available.
2. Other turning point available.
3. Higher shock and vibration available.
FIGURE 2
CX1H TYPICAL MOTIONAL CAPACITANCE (C
1
)
FIGURE 3
CX1H TYPICAL QUALITY FACTOR (Q)
CX1HSM Standard Calibration T
olerance at 25
O
C
Frequency Range (kHz)
10-74.9
30 ppm
(0.003%)
+
_
+
_
75-169.9
50 ppm
(0.005%)
+
_
+
_
170-249.9
+
_
250-600
+
_
100 ppm
(0.01%)
200 ppm
(0.02%)
200 ppm
(0.02%)
500 ppm
(0.05%)
FIGURE 4
CX1H TYPICAL TURNING POINT TEMP (T
0
)
.
100 ppm
(0.01%)
100 ppm
(0.01%)
+
_
+
_
+
_
1000 ppm
(0.1%)
+
_
1000 ppm
(0.1%)
+
_
2000 ppm
(0.2%)
+
_
5000 ppm
(0.5%)
HOW TO ORDER CX1HSM CRYSTALS
CX1H
“S” if special or
custom design.
Blank if Std.
Blank= Glass Lid
C=Ceramic Lid
S
C
SM1
32.768K
Frequency
K = kHz
,
30
Calibration
Tolerance
@ 25
O
C
(in ppm)
/
I
SM1 = Gold Plated (Lead Free)
SM2 = Solder Plated
SM3 = Solder Dipped
SM4 = Solder Plated (Lead Free)
SM5 = Solder Dipped (Lead Free)
Operating Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
TERMINATIONS
Designation
SM1
SM2
SM3
SM4
SM5
Termination
Gold Plated (Lead Free)
Solder Plated
Solder Dipped
Solder Plated (Lead Free)
Solder Dipped (Lead Free)
Note: Frequency f at temperature T is related to frequency f
0
at
turning point temperature T
0
by:
f-f
2
0
=
k(T-T
0
)
f
0
PACKAGING
CX1HSM
- Tray Pack
- 16mm tape, 7” or 13” reels
(Reference tape and reel data sheet 10109)
10122 - Rev E
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
