2-440408-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 2-440408-2

2-440408-2: Description25 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER, RECEPTACLE; CategoryThe connector The connector; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

2-440408-2 Overview

25 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER, RECEPTACLE

2-440408-2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	AMPLIMITE
body width	1.244 inch
subject depth	0.761 inch
body length	2.088 inch
Body/casing type	RECEPTACLE
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	GOLD FLASH
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	STAGGERED
Contact resistance	30 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	500VAC V
empty shell	NO
Filter function	NO
IEC compliance	NO
Insulation resistance	1000000000 Ω
Insulator color	BURGUNDY
insulator material	POLYBUTYLENE TEREPHTHALATE
MIL compliance	NO
Manufacturer's serial number	440408
Plug contact pitch	0.109 inch
Match contact row spacing	0.112 inch
Mixed contacts	NO
Installation option 1	#4-40
Installation option 2	SCREWLOCKS
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	2.8448 mm
Plating thickness	FLASH inch
Rated current (signal)	2 A
Guideline	UL, CSA
reliability	COMMERCIAL
Shell surface	TIN
Shell material	STEEL
Housing size	3/B
Terminal length	0.125 inch
Terminal pitch	2.7686 mm
Termination type	SOLDER
Total number of contacts	25
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

D-Subminiature C onnectors

Product Feature Selector

> Product Details

2-440408-2 Product Details

Live Product Chat

Stacked Connectors

5 of 6 EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

2-440408-2

T E I nternal N umber: 2 - 4 4 0 4 0 8 - 2

Product Highlights:

C onnector C onfiguration [Upper C onn./Lower C onn.] =

High Rise

Receptacle over Bracket

Mating C onnector Lock Type = Female Screwlocks

Without Mating Polarization

Yes PC B Retention Feature

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information

C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

AMPLIMITE SUBMINATURE D TYPE C ONNEC TORS

(PDF, English)

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Gender

= Receptacle over Bracket

Mating C onnector Lock Type

= Female Screwlocks

Mating Polarization = Without

PC B Retention Feature

= Yes

Stacked Number of Positions [Upper C onn./Lower C onn.]

= 25/0

Shell Type = Front Metal Shell

Product Series = Series III

C olor C ode = PC 99 Standard

Pin/Socket = Socket (Upper)/Bracket (Lower)

PC B Mount Angle = Right Angle

Shell Material = Steel

Bracket Material = C opper Alloy

Mechanical Attachment:

Female Screwlock Material = Brass

Termination Related Features:

Termination Post Length (mm [in]) = 3.18 [0.125]

Body Related Features:

C onnector C onfiguration [Upper C onn./Lower C onn.]

= High Rise

C enterline, Matrix (mm [in])

= 1.37 x 2.84 [.054 x .112]

PC B Retention Method = Boardlock(s)

Shell Plating = Tin

Contact Related Features:

C ontact Mating Area Plating Material

= Gold Flash

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing C olor = Burgundy

Housing Material = PBT

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Other:

Brand = AMP

Additional Information:

Product Line Information
