227670-1 Product Details
Live Product Chat
Product Photo
BNC RF Connectors
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
227670-1
T E I nternal N umber: 2 2 7 6 7 0 - 1
Product Highlights:
l
C onnector
l
C onnector Type = BNC
l
Jack
l
Terminate To Printed C ircuit Board
l
PC B Mount Angle = Vertical
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
RF C OAXIAL SOLUTIONS FOR C OMMUNIC ATIONS
(PDF, English)
l
RF C OAX PRODUC TS
(PDF, English)
Product Specifications:
l
BNC PC B Straight and Right Angle C onnectors
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
C ommercial BNC Jack C onnectors f/PC Board and Panel ...
(PDF, English)
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= BNC
l
Gender
= Jack
l
PC B Mount Angle
= Vertical
l
Grade
= C ommercial
l
PC B Height (mm [in])
= 34.93 [1.375]
l
PC B Retention Feature
= No
l
Body Material
= Diecast Zinc
l
Body Insulation
= Without
l
Sealed
= No
l
Isolated
= No
l
Dielectric Material
= Polymethylpentene
l
Number of Ports = 1
l
Solder Terminal = Without
l
C omment = If an Insulating Bushing is required, see Part Number
330620.
Mechanical Attachment:
l
Surface Mountable = No
l
Panel Attachment
= With
l
Panel Attachment Method = Lockwasher and Nut
l
Panel Attachment Style = Rear Mount
Electrical Characteristics:
l
C onnector Impedance (?)
= 50
Body Related Features:
l
Hardware Included
= No
l
Body Plating
= Nickel
l
Polarized
= No
Contact Related Features:
l
C enter C ontact Material
= Phosphor Bronze
l
C enter C ontact Plating
= Tin-Lead
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
