2-557100-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 2-557100-9

2-557100-9: DescriptionCONNECTOR,D-SHELL,PCB MNT,RECEPT,120 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL; CategoryThe connector The connector; File Size42KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

2-557100-9 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	2-557100-9	-	-	View	Buy Now

2-557100-9 Overview

CONNECTOR,D-SHELL,PCB MNT,RECEPT,120 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL

2-557100-9 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	compli
ECCN code	EAR99
body width	0.301 inch
subject depth	0.693 inch
body length	3.391 inch
Body/casing type	RECEPTACLE
Contact to complete cooperation	AU
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	35 mΩ
Dielectric withstand voltage	250VAC V
maximum insertion force	.8896 N
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
Manufacturer's serial number	557100
Plug contact pitch	0.05 inch
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	4
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	STAGGERED
PCB contact row spacing	1.905 mm
Plating thickness	30u inch
Rated current (signal)	1 A
reliability	COMMERCIAL
Terminal length	0.134 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	120
Base Number Matches	1

Preview

Download Datasheet

View All

2-557100-9 Related Products

	2-557100-9	557100-9	3-557100-3	557100-1
Description	CONNECTOR,D-SHELL,PCB MNT,RECEPT,120 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL	CONNECTOR,D-SHELL,PCB MNT,RECEPT,50 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL	CONNECTOR,D-SHELL,PCB MNT,RECEPT,130 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL	CONNECTOR,D-SHELL,PCB MNT,RECEPT,30 CONTACTS,PIN,0.05 PITCH,R ANGLE PC TAIL TERMINAL
Reach Compliance Code	compli	compli	unknown	unknown
body width	0.301 inch	0.301 inch	0.301 inch	0.301 inch
subject depth	0.693 inch	0.693 inch	0.693 inch	0.693 inch
body length	3.391 inch	1.641 inch	3.641 inch	1.141 inch
Body/casing type	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE
Contact to complete cooperation	AU	AU	AU	AU
Contact point gender	MALE	MALE	MALE	MALE
Contact material	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE
contact mode	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Contact resistance	35 mΩ	35 mΩ	35 mΩ	35 mΩ
Dielectric withstand voltage	250VAC V	250VAC V	250VAC V	250VAC V
maximum insertion force	.8896 N	.8896 N	.8896 N	.8896 N
Insulation resistance	1000000000 Ω	1000000000 Ω	1000000000 Ω	1000000000 Ω
Insulator color	BLACK	BLACK	BLACK	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)	LIQUID CRYSTAL POLYMER (LCP)	LIQUID CRYSTAL POLYMER (LCP)	LIQUID CRYSTAL POLYMER (LCP)
Manufacturer's serial number	557100	557100	557100	557100
Plug contact pitch	0.05 inch	0.05 inch	0.05 inch	0.05 inch
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD
PCB row number	4	4	4	4
Number of rows loaded	2	2	2	2
Maximum operating temperature	105 °C	105 °C	105 °C	105 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
PCB contact pattern	STAGGERED	STAGGERED	STAGGERED	STAGGERED
PCB contact row spacing	1.905 mm	1.905 mm	1.905 mm	1.905 mm
Plating thickness	30u inch	30u inch	30u inch	30u inch
Rated current (signal)	1 A	1 A	1 A	1 A
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal length	0.134 inch	0.134 inch	0.134 inch	0.134 inch
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Termination type	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	120	50	130	30
Base Number Matches	1	1	1	1
