F4105-250: DescriptionHCMOS Output Clock Oscillator, 1MHz Min, 170MHz Max, 25MHz Nom, CMOS, ROHS COMPLIANT, SMD, 4 PIN; CategoryPassive components oscillator; File Size153KB，5 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric Compare View All

F4105-250 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	F4105-250	-	-	View	Buy Now

F4105-250 Overview

HCMOS Output Clock Oscillator, 1MHz Min, 170MHz Max, 25MHz Nom, CMOS, ROHS COMPLIANT, SMD, 4 PIN

F4105-250 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	FOX [Fox Electronics]
package instruction	DILCC4,.2,200
Reach Compliance Code	compliant
ECCN code	EAR99
Frequency Adjustment - Mechanical	NO
frequency stability	50%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	4
Maximum operating frequency	170 MHz
Minimum operating frequency	1 MHz
Nominal operating frequency	25 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Oscillator type	HCMOS
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	DILCC4,.2,200
power supply	3.3 V
Certification status	Not Qualified
Maximum slew rate	40 mA
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Terminal surface	Gold (Au) - with Nickel (Ni) barrier

Preview

Download Datasheet

View All

HCMOS 7x5mm SMD Oscillator

•

HCMOS Output

•

Stabilities to ±20 PPM

•

Temperature Ranges as wide as -40ºC

to +85ºC

•

Supply Voltages: 1.8V, 2.5V, 3.3V

O7HS

DATASHEET

(former F4500, F4400, F4100 Series)

1.8V ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

STG

)

Supply Voltage

)

Input Current

)

0.012 ~ 32.000 MHz

>32.000

~ 70.000 MHz

>70.000 ~ 120.000 MHz

>120.000 ~ 160.000 MHz

Standby Current

Output Symmetry (50% V

)

Rise/Fall Time (20%/80% V

Levels) (T

)

0.012

~ 32.000 MHz

>32.000

~ 120.000 MHz

>120.000 ~ 160.000 MHz

Output Voltage

)

Output Current

)

Output Load

(HCMOS)

Start-up Time

)

Output Disable Time

Output Enable Time

ENABLE / DISABLE FUNCTION

Pin1

Output (pin 3)

OPEN

Active

‘1’ Level V

≥

70%V

High Z

‘0’ Level V

≤

30%V

MAX (unless otherwise noted)

0.012 ~ 160.000 MHz

-55 ~ +125°C

1.8V±5%

5 mA

10 mA

15 mA

30 mA

10 uA

40 % ~ 60 %

5.0 nS

3.5 nS

3.0 nS

20% V

80% V

Min

2 mA Min

-2 mA Min

15 pF

10 mS

300 nS

10 mS

•

Available Options by Stability & Operating Temp for 1.8V

Frequency

Stability

±100PPM

±50PPM

±25PPM

±20PPM*

Operating

Temperature (ºC)

Frequency Range (MHz)

-10 ~ +70

-20 ~ +70

-40 ~ +85

-10 ~ +70

-20 ~ +70

-40 ~ +85

-10 ~ +70

-20 ~ +70

-40 ~ +85

-10 ~ +70

-20 ~ +70

0.012

~ 160.000

An internal pull-up resistor from pin 1 to pin 4 allows active output if pin 1 is left open

Inclusive of 25°C tolerance, operating temperature range, input voltage change, load change, reflow, and one year aging. *Excludes Shock/Vibration.

Title / Description:

O7HS

SERIES STANDARD SPECIFICATIONS

Drawing Number:

101147

Size: A

Cage:

61429

Part Number:

Draftsperson:

CMR

Approved:

BEC

Revision Date:

10/10/2017

Page
