HY62QF8100C Series
128Kx8bit full CMOS SRAM
DESCRIPTION
The HY62QF8100C is a high speed, super low
power and 1M bit full CMOS SRAM organized as
131,072 words by 8bit. The HY62QF8100C uses
high performance full CMOS process technology
and designed for high speed low power circuit
technology. It is particularly well suited for used in
high density low power system application. This
device has a data retention mode that guarantees
data to remain valid at a minimum power supply
voltage of 1.2V.
FEATURES
•
Fully static operation and Tri-state output
•
TTL compatible inputs and outputs
•
Battery backup(LL/SL-part)
- 1.2V(min) data retention
•
Standard pin configuration
-. 48 - FBGA
-. 32 - sTSOPI - 8X13.4(Standard)
Product
Voltage
Speed
No.
(V)
(ns)
HY62QF8100C
2.3~2.7 70/85/100
HY62QF8100C-I
2.3~2.7 70/85/100
Note 1. Blank : Commercial, I : Industrial
2. Current value is max.
Operation
Current/Icc(mA)
3
3
Standby Current(uA)
LL
SL
3
1
3
1
Temperature
°C
0~70
-40~85(I)
PIN CONNECTION
A0
A1
CS2 A3
/WE A4
NC
A5
A6
A7
A8
IO1
IO2
Vcc
Vss
NC
NC
IO3
A11
A9
A8
A13
/WE
CS2
A15
Vcc
NC
A16
A14
A12
A7
A6
A5
A4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
/OE
A10
/CS1
DQ8
DQ7
DQ6
DQ5
DQ4
Vss
DQ3
DQ2
DQ1
A0
A16
A1
A2
A3
/CS1
CS2
A0
BLOCK DIAGRAM
ROW
DECODER
SENSE AMP
I/O1
IO5 A2
IO6
Vss
Vcc
IO7
ADD INPUT
BUFFER
BUFFER
COLUMN
DECODER
MEMORY ARRAY
128K x 8
WRITE DRIVER
IO8 /OE /CS1 A16 A15 IO4
A9
A10 A11 A12 A13 A14
I/O8
CONTROL
LOGIC
FBGA
sTSOP l
/OE
/WE
PIN DESCRIPTION
Pin Name
/CS1
CS2
/WE
/OE
Pin Function
Chip Select 1
Chip Select 2
Write Enable
Output Enable
Pin Name
A0 ~ A16
I/O1 ~ I/O8
Vcc
Vss
Pin Function
Address Inputs
Data Inputs / Outputs
Power( 2.3V~2.7V)
Ground
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any
responsibility for use of circuits described. No patent licenses are implied.
Rev.02 /Jun. 00
Hyundai Semiconductor
HY62QF8100C Series
ORDERING INFORMATION
Part No.
HY62QF8100CLLF
HY62QF8100CSLF
HY62QF8100CLLF-I
HY62QF8100CSLF-I
HY62QF8100CLLST
HY62QF8100CSLST
HY62QF8100CLLST-I
HY62QF8100CSLST-I
Speed
70/85/100
70/85/100
70/85/100
70/85/100
70/85/100
70/85/100
70/85/100
70/85/100
Power
LL-part
SL-part
LL-part
SL-part
LL-part
SL-part
LL-part
SL-part
Temp.
Package
FBGA
FBGA
FBGA
FBGA
sTSOP I (standard)
sTSOP I (standard)
sTSOP I (standard)
sTSOP I (standard)
I
I
I
I
Note 1. Blank : Commercial, I : Industrial
ABSOLUTE MAXIMUM RATING (1)
Symbol
V
IN,
V
OUT
Vcc
T
A
T
STG
P
D
T
SOLDER
Parameter
Input/Output Voltage
Power Supply
Operating Temperature
Storage Temperature
Power Dissipation
Lead Soldering Temperature & Time
Rating
-0.2 to 3.6
-0.2 to 4.6
0 to 70
-40 to 85
-55 to 150
1.0
260 10
Unit
V
V
°C
°C
°C
W
°C
sec
Remark
HY62QF8100C
HY62QF8100C-I
Note
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent
damage to the device. This is stress rating only and the functional operation of the device under these or
any other conditions above those indicated in the operation of this specification is not implied.
Exposure to the absolute maximum rating conditions for extended period may affect reliability.
TRUTH TABLE
/CS1
H
X
L
L
L
CS2
X
L
H
H
H
/WE
X
X
H
H
L
/OE
X
X
H
L
X
Mode
Deselected
Deselected
Output Disabled
Read
Write
I/O
High-Z
High-Z
High-Z
Data Out
Data In
Power
Standby
Standby
Active
Active
Active
Note :
1. H=V
IH
, L=V
IL
, X=don't care(V
IN
= V
IH
or V
IL)
Rev.02 /Jun. 00
2
HY62QF8100C Series
RECOMMENDED DC OPERATING CONDITION
Symbol
Vcc
Vss
V
IH
V
IL
Parameter
Supply Voltage
Ground
Input High Voltage
Input Low Voltage
Min.
2.3
0
2.0
-0.3
(1)
Typ.
2.5
0
-
-
Max.
2.7
0
Vcc+0.3
0.6
Unit
V
V
V
V
Note : 1. VIL = -1.5V for pulse width less than 30ns
2. Undershoots are sampled and not 100% tested.
DC ELECTRICAL CHARACTERISTICS
Vcc = 2.3~2.7V, T
A
= 0°C to 70°C / -40°C to 85°C (I), unless otherwise specified
Sym
Parameter
Test Condition
Min.
I
LI
Input Leakage Current
Vss < V
IN
< Vcc
-1
I
LO
Output Leakage Current
Vss < V
OUT
< Vcc, /CS1 = V
IH
or
-1
CS2 = V
IL
or
/
OE
=
V
IH
or /WE = V
IL
Icc
Operating Power Supply
/CS1 = V
IL
, CS2 = V
IH,
-
Current
V
IN
= V
IH
or V
IL,
I
I/O =
0mA
I
CC1
Average Operating Current
/CS1 < 0.2V,
1us
Cycle
-
Time,100%Duty, I
I/O =
0mA,
V
IN
< 0.2V
/CS1 = V
IL
, CS2 = V
IH
,
VIN = V
IH
or V
IL
, IIO = 0mA
Cycle Time = Min, 100% duty
I
SB
TTL Standby Current
/CS1 = V
IH
or CS2 = V
IL
-
(TTL Input)
I
SB1
Standby Current
/CS1 > Vcc - 0.2V
SL
-
(CMOS Input)
CS2 < 0.2V or
LL
-
CS2 > Vcc - 0.2V
V
OL
Output Low Voltage
I
OL
= 0.5mA
-
V
OH
Output High Voltage
I
OH =
-0.5mA
2.0
Note : 1.Typical values are at Vcc = 2.5V, T
A
= 25°C
2.Typical values are sampled and not 100% tested.
Typ.
-
-
-
-
Max.
1
1
3
4
Unit
uA
uA
mA
mA
30
mA
-
-
0.5
-
-
0.3
1
3
0.4
-
mA
uA
uA
V
V
CAPACITANCE
(Temp = 25°C, f= 1.0MHz)
Symbol
Parameter
C
IN
Input Capacitance(Add, /CS1, /WE, /OE)
C
OUT
Output Capacitance(I/O)
Condition
V
IN
= 0V
V
I/O
= 0V
Max.
8
10
Unit
pF
pF
Note : These parameters are sampled and not 100% tested
Rev.02 /Jun. 00
3
HY62QF8100C Series
AC CHARACTERISTICS
Vcc = 2.3V~2.7V, T
A
= 0°C to 70°C / -40°C to 85°C (I), unless otherwise specified
-70
-85
# Symbol
Parameter
Min.
Max. Min.
Max.
READ CYCLE
1
tRC
Read Cycle Time
70
-
85
-
2
tAA
Address Access Time
-
70
-
85
3
tACS
Chip Select Access Time
-
70
-
85
4
tOE
Output Enable to Output Valid
-
40
-
45
5
tCLZ
Chip Select to Output in Low Z
10
-
10
-
6
tOLZ
Output Enable to Output in Low Z
5
-
5
-
7
tCHZ
Chip Deselection to Output in High Z
0
30
0
30
8
tOHZ
Out Disable to Output in High Z
0
30
0
30
9
tOH
Output Hold from Address Change
10
-
10
-
WRITE CYCLE
10 tWC
Write Cycle Time
70
-
85
-
11 tCW
Chip Selection to End of Write
60
-
70
-
12 tAW
Address Valid to End of Write
60
-
70
-
13 tAS
Address Set-up Time
0
-
0
-
14 tWP
Write Pulse Width
50
-
55
-
15 tWR
Write Recovery Time
0
-
0
-
16 tWHZ
Write to Output in High Z
0
25
0
30
17 tDW
Data to Write Time Overlap
30
-
35
-
18 tDH
Data Hold from Write Time
0
-
0
-
19 tOW
Output Active from End of Write
5
-
5
-
-10
Min
Max.
100
-
-
-
20
5
0
0
15
100
80
80
0
75
0
0
45
0
10
-
100
100
50
-
-
30
30
-
-
-
-
-
-
-
35
-
-
-
Unit
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
AC TEST CONDITIONS
T
A
= 0°C to 70°C / -40°C to 85°C (I), unless otherwise specified
Parameter
Value
Input Pulse Level
0.4V to 2.2V
Input Rise and Fall Time
5ns
Input and Output Timing Reference Level
1.1V
Output Load
CL = 30pF + 1TTL Load
AC TEST LOADS
V
TM=2.3V
3067 Ohm
D
OUT
CL(1)
3345 Ohm
Note
1. Including jig and scope capacitance
Rev.02 /Jun. 00
4
HY62QF8100C Series
TIMING DIAGRAM
READ CYCLE 1(Note 1, 4)
tRC
ADDR
tAA
tACS
/CS1
tOH
CS2
tCHZ
(3)
/OE
tOE
tOLZ
(3)
Data
Out
tCLZ
(3)
High-Z
Data Valid
tOHZ
(3)
READ CYCLE 2(Note 1,2,4)
tRC
ADDR
tAA
tOH
Data
Out
Previous Data
Data Valid
tOH
READ CYCLE 3(Note 1,2,4)
/CS1
CS2
tACS
tCLZ
(3)
Data
Out
Data Valid
tCHZ
(3)
Notes:
1. Read Cycle occurs whenever a high on the /WE and /OE is low /CS1 and CS2 are in active status.
2. /OE = V
IL
3. Transition is measured + 200mV from steady state voltage.
This parameter is sampled and not 100% tested.
4. /CS1 in high for the standby, low for active
CS2 in low for the standby, high for active
Rev.02 /Jun. 00
5
