2-382804-0

Description
HEADER,JUMPER/SHUNT,40 CONTACTS,SKT,0.1 PITCH,BLACK
CategoryThe connector    The connector
File Size103KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

2-382804-0 Overview

HEADER,JUMPER/SHUNT,40 CONTACTS,SKT,0.1 PITCH,BLACK

2-382804-0 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknow
body width0.2 inch
subject depth0.25 inch
body length1.996 inch
Body/casing typePLUG
Connector typeSHUNTS / JUMPER CONNECTOR
Contact to complete cooperationAU ON NI
Contact point genderFEMALE
Contact materialPHOSPHOR BRONZE
contact modeRECTANGULAR
Contact styleSQ PIN-SKT
Dielectric withstand voltage1000VAC V
Insulator colorBLACK
insulator materialGLASS FILLED THERMOPLASTIC
Manufacturer's serial number382804
Plug contact pitch0.1 inch
Match contact row spacing0.1 inch
Installation methodSTRAIGHT
Number of connectorsONE
Number of rows loaded2
Maximum operating temperature105 °C
Minimum operating temperature-55 °C
Plating thickness15u inch
Rated current (signal)2.5 A
GuidelineUL, CSA
reliabilityCOMMERCIAL
Total number of contacts40
Base Number Matches1

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
PC B C onnectors
>
Product Feature Selector
> Product Details
2-382804-0 Product Details
Live Product Chat
Product Photo
Post Shunts
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
2-382804-0
T E I nternal N umber: 2 - 3 8 2 8 0 4 - 0
Product Highlights:
l
Shunt Type = Multiposition
l
2.54 mm C enterline
l
Gold (15) C ontact Mating Area Plating Material
l
Grid Size = 2x20
l
Without Handle
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
Multiposition Shunt C onnectors 390102 and 382909
(PDF, English)
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Shunt Type
= Multiposition
l
Grid Size
= 2x20
l
C SA C ertified = Yes
Termination Related Features:
l
Height (mm [in]) = 6.35 [0.250]
Body Related Features:
l
C enterline (mm [in])
= 2.54 [0.100]
l
Handle = Without
l
UL Rating = Recognized
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold (15)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing C olor = Black
l
Housing Material = Polyester GF
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
