2.5SB
HEADER
2.5mm
pitch
Headers
The SB headers can be used to connect
any 2.5mm receptacles to printed circuit
boards. They can also be used to directly
connect PC boards. They come in pitches
of 2.5mm and in both top entry and side
entry type models.
2.54mm pitch SB headers are also
available. In addition, 2.0mm pitch BC
headers are available.
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Post: Brass, copper-undercoated,
tin-plated (reflow treatment)
• Wafer: PA 66, UL94V-0(natural)
• Pitch: 2.5mm
• Number of circutis: 2 to 20
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
1
2.5SB
HEADER
Header ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
Model No.
SB( )P-HVQ-A
SB( )P-HVQ-B
SB( )P-HVQ-C
B
Dimensions (mm)
A
5.0
4.0
0.4
3.4
3.4
6.35
6.3
3.3
3.4
3.5
3.4
4.0
1.5
2.5
3.4
3.3
B
16.5
8.7
10.5
7.5
6.0
6.35
13.7
7.5
11.1
5.7
13.7
3.5
5.1
14.0
14.8
3.3
C
24.8
16.0
14.2
14.2
12.7
16.0
23.3
14.1
17.8
12.5
20.4
10.8
9.9
19.8
21.5
9.9
SB( )P-HVQ-CA
SB( )P-HVQ-S
C
3.3
SB( )P-HVQ-N
SB( )P-HVQ-15
SB( )P-HVQ-16
SB( )P-HVQ-22
SB( )P-HVQ-23
SB( )P-HVQ-24
SB( )P-HVQ-27
SB( )P-HVQ-28
SB( )P-HVQ-29
SB( )P-HVQ-30
SB( )P-HVQ-34
2.5
2.4
2.5x(N-1)
2.5xN
(1.25)
0.64
Note: N --- Number of circuits
A
RoHS compliance
This product displays (LF)(SN) on a label.
*The number of circuits (2 to 20) will be filled in the parentheses above.
Side entry type
B
Model No.
MB( )P-90
MB( )P-90H
MB( )P-90S
MB( )P-90-2
C
Dimensions (mm)
A
3.5
3.4
4.3
2.3
B
3.5
7.6
7.9
2.5
C
8.8
9.7
8.3
7.6
RoHS compliance
This product displays (LF)(SN) on a label.
*The number of circuits (2 to 20) will be filled in the parentheses above.
2.5
2.4
2.5x(N-1)
2.5xN
(1.25)
0.64
Note: N --- Number of circuits
PC board layout
(viewed from soldering side)
––––––––––––––––––––––––––––––––––––––
Note:
1. Tolerances are non-cumulative: ±0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing
method. The dimensions above should serve as a guideline.
Contact JST for details.
2.5±0.05 1.25min.
φ
0.9
+0.1
0
2
A
3.3
