FX5545G305ADJ: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 10W, BGA-20; CategoryPower/power management The power supply circuit; File Size108KB，2 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

FX5545G305ADJ Overview

DC-DC Regulated Power Supply Module, 1 Output, 10W, BGA-20

FX5545G305ADJ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Vishay
Parts packaging code	MODULE
package instruction	BGA,
Contacts	20
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	SELF SELECTABLE OUTPUT VOLTAGE
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	6 V
Minimum input voltage	2.7 V
Nominal input voltage	3.6 V
JESD-30 code	R-XBGA-B20
JESD-609 code	e0
length	14.7 mm
Number of functions	1
Output times	1
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	4.5 V
Minimum output voltage	1.35 V
Package body material	UNSPECIFIED
encapsulated code	BGA
Package shape	RECTANGULAR
Package form	GRID ARRAY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	3 mm
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	BALL
Terminal pitch	2.54 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	10 W
Fine-tuning/adjustable output	YES
width	12.2 mm

Preview

Download Datasheet

View All

Self Selectable Output Voltage

Vishay

Buck or Boost with High Output Density Power

DESCRIPTION

The DC/DC converter provides fully integrated synchronous

Buck or Boost converter solution for the latest one-cell lithium

ion cellular phones. Its input voltage is between 2.5V to 6V

capable of delivering up to 4A output current. An external

resistor according to the formulas respectively, can adjust

an output voltage between 0.8V, 0.9V to 1.3V and 1.35V to

4.5V for Buck and 3.3V to 6V for Boost.

*The numbers are for illustration purpose only.

PRODUCT DESCRIPTION

INPUT

OUTPUT

TYPE

MOUNTING

TOPOLOGY

VOLTAGE (V)

FX5545G001ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G201ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G005ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G105ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G205ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G305ADJ

BGA or LGA

Buck

2.7-6.0

1.35-4.5*

FX5545G008ADJ

BGA or LGA

Buck

2.5-6.0

0.8-4.5*

FX5545G018ADJ

BGA or LGA

Buck

2.5-6.0

0.9-1.3

FX5545G108ADJ

BGA or LGA

Buck

2.5-6.0

0.9-4.5*

FX5545G002ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

FX5545G202ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

FX5545G402ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

FX5545G006ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

FX5545G106ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

FX5545G206ADJ

BGA or LGA

Boost

2.5-6.0

3.3-6.0

*Note:

For higher output voltage please consult factory at FunctionPAK@Vishay.com

MAX OUTPUT

CURRENT (A)

0.6

1.0

1.5

2.0

2.5

3.0

4.0

0.3

0.6

1.0

1.5

2.0

2.5

OUTPUT

POWER (W)

1.5

3.0

5.0

6.5

8.2

10.0

3.6

15.0

1.5

3.0

5.0

9.0

12.0

15.0

R

EXT

/D

EXT

SELECTION

COMPONENT

TYPE

FX5545G001ADJ

FX5545G201ADJ

FX5545G005ADJ

FX5545G105ADJ

FX5545G205ADJ

FX5545G305ADJ

FX5545G008ADJ

TOPOLOGY

REQUESTED

OUTPUT VOLTAGE

1.35V - 4.5V

R

EXT

DEVICE

R

EXT

[KΩ] =

R

EXT

[KΩ] =

28.6

V

OUT

- 1.3

71.5

V

OUT

- 1.3

D

EXT

DEVICE

N/C

1.35V - 4.5V

N/C

0.8V - 1.3V

Buck

1.35V - 4.5V

FX5545G018ADJ

0.9V - 1.3V

FX5545G108ADJ

1.35V - 4.5V

FX5545G002ADJ

FX5545G202ADJ

FX5545G402ADJ

FX5545G006ADJ

FX5545G106ADJ

FX5545G206ADJ

3.3V - 6.0V

Boost

3.3V - 6.0V

52

(V

OUT

- 0.75) V

OUT

71.5

R

EXT

[KΩ] =

V

OUT

- 1.3

66

R

EXT

[KΩ] =

(1.2V

OUT

- 1) V

OUT

66

R

EXT

[KΩ] =

(1.2V

OUT

- 1) V

OUT

R

EXT

[KΩ] =

R

EXT

[KΩ] =

R

EXT

[KΩ] =

71.5

V

OUT

- 1.3

28.6

V

OUT

- 1.3

71.5

V

OUT

- 1.3

D2-MCL4448

N/C

D2-BAR65V

N/C

R

EXT

[KΩ] =

N/C

Document Number: 10116

Revision 06-Apr-04

For technical questions, contact FunctionPAK@vishay.com

For marketing questions, contact FunctionPAK.marketing@vishay.com

www.vishay.com

51
