HUF75345G3, HUF75345P3, HUF75345S3S
Data Sheet
December 2009
75A, 55V, 0.007 Ohm, N-Channel UltraFET
Power MOSFETs
These N-Channel power MOSFETs
are manufactured using the
innovative UltraFET® process. This
advanced process technology
achieves the lowest possible on-resistance per silicon area,
resulting in outstanding performance. This device is capable
of withstanding high energy in the avalanche mode and the
diode exhibits very low reverse recovery time and stored
charge. It was designed for use in applications where power
efficiency is important, such as switching regulators,
switching converters, motor drivers, relay drivers, low-
voltage bus switches, and power management in portable
and battery-operated products.
Formerly developmental type TA75345.
Features
• 75A, 55V
• Simulation Models
- Temperature Compensated PSPICE® and SABER™
Models
- Thermal Impedance SPICE and SABER Models
Available on the WEB at: www.fairchildsemi.com
• Peak Current vs Pulse Width Curve
• UIS Rating Curve
• Related Literature
- TB334, “Guidelines for Soldering Surface Mount
Components to PC Boards”
Symbol
D
Ordering Information
PART NUMBER
HUF75345G3
HUF75345P3
HUF75345S3S
PACKAGE
TO-247
TO-220AB
TO-263AB
BRAND
75345G
75345P
75345S
S
G
NOTE: When ordering, use the entire part number. Add the suffix T to
obtain the TO-263AB variant in tape and reel, e.g., HUF75345S3ST.
Packaging
JEDEC STYLE TO-247
SOURCE
DRAIN
GATE
DRAIN
(FLANGE)
JEDEC TO-220AB
SOURCE
DRAIN
GATE
DRAIN
(TAB)
JEDEC TO-263AB
GATE
SOURCE
DRAIN
(FLANGE)
Product reliability information can be found at http://www.fairchildsemi.com/products/discrete/reliability/index.html
For severe environments, see our Automotive HUFA series.
All Fairchild semiconductor products are manufactured, assembled and tested under ISO9000 and QS9000 quality systems certification.
©2009 Fairchild Semiconductor Corporation
HUF75345G3, HUF75345P3, HUF75345S3S Rev. B2
HUF75345G3, HUF75345P3, HUF75345S3S
Absolute Maximum Ratings
T
C
= 25
o
C, Unless Otherwise Specified
UNITS
Drain to Source Voltage (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
DSS
Drain to Gate Voltage (R
GS
= 20kΩ) (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
DGR
Gate to Source Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
GS
Drain Current
Continuous (Figure 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
D
Pulsed Drain Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .I
DM
Pulsed Avalanche Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E
AS
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P
D
Derate Above 25
o
C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T
J
, T
STG
Maximum Temperature for Soldering
Leads at 0.063in (1.6mm) from Case for 10s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T
L
Package Body for 10s, See Techbrief 334 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T
pkg
55
55
±20
75
Figure 4
Figure 6
325
2.17
-55 to 175
300
260
W
W/
o
C
o
C
o
C
o
C
V
V
V
A
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTE:
1. T
J
= 25
o
C to 150
o
C.
Electrical Specifications
PARAMETER
OFF STATE SPECIFICATIONS
T
C
= 25
o
C, Unless Otherwise Specified
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNITS
Drain to Source Breakdown Voltage
Zero Gate Voltage Drain Current
BV
DSS
I
DSS
I
GSS
V
GS(TH)
r
DS(ON)
R
θJC
R
θJA
I
D
= 250µA, V
GS
= 0V (Figure 11)
V
DS
= 50V, V
GS
= 0V
V
DS
= 45V, V
GS
= 0V, T
C
= 150
o
C
V
GS
=
±20V
V
GS
= V
DS
, I
D
= 250µA (Figure 10)
I
D
= 75A, V
GS
= 10V (Figure 9)
(Figure 3)
TO-247
TO-220, TO-263
55
-
-
-
-
-
-
-
-
1
250
±100
4
0.007
V
µA
µA
nA
Gate to Source Leakage Current
ON STATE SPECIFICATIONS
Gate to Source Threshold Voltage
Drain to Source On Resistance
THERMAL SPECIFICATIONS
Thermal Resistance Junction to Case
Thermal Resistance Junction to Ambient
2
-
-
0.006
V
W
o
C/W
o
C/W
o
C/W
-
-
-
-
-
-
0.46
30
62
SWITCHING SPECIFICATIONS
(V
GS
= 10V)
Turn-On Time
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
Fall Time
Turn-Off Time
GATE CHARGE SPECIFICATIONS
Total Gate Charge
Gate Charge at 10V
Threshold Gate Charge
Gate to Source Gate Charge
Gate to Drain “Miller” Charge
Q
g(TOT)
Q
g(10)
Q
g(TH)
Q
gs
Q
gd
V
GS
= 0V to 20V
V
GS
= 0V to 10V
V
GS
= 0V to 2V
V
DD
= 30V,
I
D
≅
75A,
R
L
= 0.4Ω
I
g(REF)
= 1.0mA
(Figure 13)
-
-
-
-
-
220
125
6.8
14
58
275
165
10
-
-
nC
nC
nC
nC
nC
t
ON
t
d(ON)
t
r
t
d(OFF)
t
f
t
OFF
V
DD
= 30V, I
D
≅
75A,
R
L
= 0.4Ω, V
GS
=
10V,
R
GS
= 2.5Ω
-
-
-
-
-
-
-
14
118
42
26
-
195
-
-
-
-
98
ns
ns
ns
ns
ns
ns
©2009 Fairchild Semiconductor Corporation
HUF75345G3, HUF75345P3, HUF75345S3S Rev. B2
HUF75345G3, HUF75345P3, HUF75345S3S
Electrical Specifications
PARAMETER
CAPACITANCE SPECIFICATIONS
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
C
ISS
C
OSS
C
RSS
V
DS
= 25V, V
GS
= 0V,
f = 1MHz
(Figure 12)
-
-
-
4000
1450
450
-
-
-
pF
pF
pF
T
C
= 25
o
C, Unless Otherwise Specified
(Continued)
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNITS
Source to Drain Diode Specifications
PARAMETER
Source to Drain Diode Voltage
Reverse Recovery Time
Reverse Recovered Charge
SYMBOL
V
SD
t
rr
Q
RR
I
SD
= 75A
I
SD
= 75A, dI
SD
/dt = 100A/µs
I
SD
= 75A, dI
SD
/dt = 100A/µs
TEST CONDITIONS
MIN
-
-
-
TYP
-
-
-
MAX
1.25
55
80
UNITS
V
ns
nC
Typical Performance Curves
1.2
POWER DISSIPATION MULTIPLIER
1.0
I
D
, DRAIN CURRENT (A)
60
0.8
0.6
0.4
0.2
0
0
25
50
75
100
125
150
175
T
C
, CASE TEMPERATURE (
o
C)
0
25
80
40
20
50
75
100
125
150
175
T
C
, CASE TEMPERATURE (
o
C)
FIGURE 1. NORMALIZED POWER DISSIPATION vs CASE
TEMPERATURE
FIGURE 2. MAXIMUM CONTINUOUS DRAIN CURRENT vs
CASE TEMPERATURE
2
1
THERMAL IMPEDANCE
Z
θJC
, NORMALIZED
DUTY CYCLE - DESCENDING ORDER
0.5
0.2
0.1
0.05
0.02
0.01
P
DM
0.1
t
1
t
2
NOTES:
DUTY FACTOR: D = t
1
/t
2
PEAK T
J
= P
DM
x Z
θJC
x R
θJC
+ T
C
10
-3
10
-2
10
-1
10
0
10
1
SINGLE PULSE
0.01
10
-5
10
-4
t, RECTANGULAR PULSE DURATION (s)
FIGURE 3. NORMALIZED MAXIMUM TRANSIENT THERMAL IMPEDANCE
©2009 Fairchild Semiconductor Corporation
HUF75345G3, HUF75345P3, HUF75345S3S Rev. B2
HUF75345G3, HUF75345P3, HUF75345S3S
Typical Performance Curves
2000
(Continued)
T
C
= 25
o
C
I
DM
, PEAK CURRENT (A)
1000
FOR TEMPERATURES
ABOVE 25
o
C DERATE PEAK
CURRENT AS FOLLOWS:
I = I
25
175 - T
C
150
V
GS
= 20V
V
GS
= 10V
TRANSCONDUCTANCE
MAY LIMIT CURRENT
IN THIS REGION
100
50
10
-5
10
-4
10
-3
10
-2
t, PULSE WIDTH (s)
10
-1
10
0
10
1
FIGURE 4. PEAK CURRENT CAPABILITY
1000
T
J
= MAX RATED
T
C
= 25
o
C
I
D
, DRAIN CURRENT (A)
1000
I
AS
, AVALANCHE CURRENT (A)
If R = 0
t
AV
= (L)(I
AS
)/(1.3*RATED BV
DSS
- V
DD
)
If R
≠
0
t
AV
= (L/R)ln[(I
AS
*R)/(1.3*RATED BV
DSS
- V
DD
) +1]
100
100µs
100
1ms
10
OPERATION IN THIS
AREA MAY BE
LIMITED BY r
DS(ON)
V
DSS(MAX)
= 55V
1
1
10
V
DS
, DRAIN TO SOURCE VOLTAGE (V)
100
200
10ms
STARTING T
J
= 25
o
C
STARTING T
J
= 150
o
C
10
0.01
0.1
1
10
100
t
AV
, TIME IN AVALANCHE (ms)
NOTE: Refer to Fairchild Application Notes AN9321 and AN9322.
FIGURE 5. FORWARD BIAS SAFE OPERATING AREA
FIGURE 6. UNCLAMPED INDUCTIVE SWITCHING CAPABILITY
150
V
GS
= 20V
V
GS
= 10V
V
GS
= 7V
V
GS
= 6V
150
PULSE DURATION = 80µs
DUTY CYCLE = 0.5% MAX
I
D
, DRAIN CURRENT (A)
V
GS
= 5V
120
I
D
, DRAIN CURRENT (A)
120
90
90
60
60
25
o
C
30
175
o
C
-55
o
C
4.5
V
DD
= 15V
6.0
7.5
30
0
PULSE DURATION = 80µs
DUTY CYCLE = 0.5% MAX
T
C
= 25
o
C
0
1
2
3
4
0
0
1.5
3.0
V
DS
, DRAIN TO SOURCE VOLTAGE (V)
V
GS
, GATE TO SOURCE VOLTAGE (V)
FIGURE 7. SATURATION CHARACTERISTICS
FIGURE 8. TRANSFER CHARACTERISTICS
©2009 Fairchild Semiconductor Corporation
HUF75345G3, HUF75345P3, HUF75345S3S Rev. B2
京公网安备 11010802033920号
EEWORLD
