2-440391-1: DescriptionCONNECTOR, 25 CONTACT(S), MALE-MALE, D SUBMINIATURE CONNECTOR, SOLDER, PLUG; CategoryThe connector The connector; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

2-440391-1 Overview

CONNECTOR, 25 CONTACT(S), MALE-MALE, D SUBMINIATURE CONNECTOR, SOLDER, PLUG

2-440391-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	1949708240
Reach Compliance Code	unknown
YTEOL	0
Other features	OTHER STACKING CONNECTOR: CONTACTS: 25 ; SHELL SIZE: 3/B
Board mount options	SPLIT BOARD LOCK
body width	1.24 inch
subject depth	0.8 inch
body length	2.08 inch
Body/casing type	PLUG
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	GOLD FLASH
Contact completed and terminated	GOLD FLASH
Contact point gender	MALE-MALE
Contact material	COPPER ALLOY
contact mode	STAGGERED
Contact style	RND PIN-SKT
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYETHYLENE
JESD-609 code	e4
MIL compliance	NO
Plug contact pitch	0.109 inch
Mixed contacts	NO
Installation option 1	#4-40
Installation option 2	SCREWLOCKS
Installation type	BOARD
Number of connectors	TWO
Number of rows loaded	2+2
Options	GENERAL PURPOSE
Rated current (signal)	3 A
Housing size	3/B
Termination type	SOLDER
Total number of contacts	50
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

D-Subminiature C onnectors

Product Feature Selector

> Product Details

2-440391-1 Product Details

Live Product Chat

Stacked Connectors

5 of 6 EU R oHS/ELV C om plia nt

(

Find R oHS C om plia nt

No Im a ge Ava ila ble

Alte rna te s

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

2-440391-1

T E I nternal N umber: 2 - 4 4 0 3 9 1 - 1

Obsolete

C ontact Product Information

C enter

Product Highlights:

C onnector C onfiguration [Upper C onn./Lower C onn.] =

Same Series

Plug over Plug

Mating C onnector Lock Type = Threaded Insert, 4-40

UNC

Without Mating Polarization

Yes PC B Retention Feature

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

AMPLIMITE SUBMINATURE D TYPE C ONNEC TORS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version C )

3D Model

(IGES, Version C )

3D Model

(STEP, Version C )

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Gender

= Plug over Plug

Mating C onnector Lock Type = Threaded Insert, 4-40 UNC

Mating Polarization = Without

PC B Retention Feature

= Yes

Stacked Number of Positions [Upper C onn./Lower C onn.]

= 25/25

Stacked Shell Size [Upper C onn./Lower C onn.]

= 3/3

Shell Type = Front Metal Shell

Product Series = Series II

C olor C ode = None

PC B Mount Angle = Right Angle

Stacked Product Series [Upper C onn./Lower/ C onn.] = HD-20 / HD-

Body Related Features:

C onnector C onfiguration [Upper C onn./Lower C onn.]

= Same Series

C enterline, Matrix (mm [in])

= 2.77 x 2.84 [.109 x .112]

Contact Related Features:

C ontact Mating Area Plating Material

= Gold Flash

C ontact Base Material = C opper Alloy

Housing Related Features:

Housing C olor = Black

Housing Material = Thermoplastic

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Other:

Brand = AMP

Additional Information:

Product Line Information
