2-794665-4: DescriptionHEADER CONNECTOR,PCB MNT,RECEPT,0+24 CONTACTS,PIN,0.165 PITCH,PC TAIL TERMINAL,LOCKING,NATURAL; CategoryThe connector The connector; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

2-794665-4 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,0+24 CONTACTS,PIN,0.165 PITCH,PC TAIL TERMINAL,LOCKING,NATURAL

2-794665-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU
Contact completed and terminated	GOLD
Contact point gender	MALE
Contact material	COPPER ALLOY
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	SQ PIN-SKT
Dielectric withstand voltage	1500VAC V
Insulation resistance	1000000000 Ω
Insulator color	NATURAL
insulator material	NYLON
Manufacturer's serial number	794665
Plug contact pitch	0.165 inch
Match contact row spacing	0.165 inch
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	RECTANGULAR
PCB contact row spacing	4.191 mm
Plating thickness	30u inch
Rated current (signal)	9 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	4.191 mm
Termination type	SOLDER
Total number of contacts	0+24
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors - Wire to Board - Power

Product Feature Selector

> Product Details

2-794665-4 Product Details

Live Product Chat

Product View

4.2mm & 4.4mm Centerline, 600 V, 9 A max. Dual Action

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

2-794665-4

T E I nternal N umber: 2 - 7 9 4 6 6 5 - 4

Product Highlights:

Header

AMP-DUAC

0 Power Positions

24 Signal Positions

PC B Mount Angle = Vertical

View all Features

Superseded

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

AMP-DUAC Headers and C onnectors

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Header

C onnector Line

= AMP-DUAC

PC B Mount Angle

= Vertical

PC B Retention Feature

= No

Mechanical Attachment:

Number of Power Positions = 0

Flange

= Without

Electrical Characteristics:

Voltage (VAC ) = 600

C urrent Rating (Amps.) = 9

Termination Related Features:

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

Number of Signal Positions = 24

Positions Unloaded

= None

Material Flammability Rating

= UL 94V-2

C enterline (mm [in]) = 4.20 [0.165]

Mount Type = Printed C ircuit Board

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (30)

C ontact Material (Signal) = C opper Alloy

Solder Process Drain Hole = Without

Housing Related Features:

Housing Material = Nylon

Housing C olor = Natural

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

High Temperature Header

= No

Other:

Brand = AMP

Additional Information:

Product Line Information
