Ver. 8.3
Power Inductors - Shielded
SPECIFICATIONS
Parts are available in ±20% tolerance only.
*
Inductance drop = 30% typ. at IDC.
Part
Number
CT921CY-1R0M
CT921CY-1R5M
CT921CY-2R2M
CT921CY-3R6M
CT921CY-4R7M
CT921CY-6R2M
CT921CY-100M
CT921CY-120M
CT921CY-150M
CT921CY-180M
CT921CY-220M
CT921CY-270M
CT921CY-330M
CT921CY-390M
CT921CY-470M
CT921CY-560M
CT921CY-680M
CT921CY-820M
CT921CY-101M
CT921CY-151M
Inductance
(µH ±20%)
1.0
1.5
2.2
3.6
4.7
6.2
10
12
15
18
22
27
33
39
47
56
68
82
100
150
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Ω
(Ω ±20%)
0.017
0.019
0.024
0.030
0.036
0.042
0.050
0.060
0.080
0.086
0.110
0.130
0.150
0.165
0.215
0.250
0.300
0.375
0.470
0.650
ctparts.com
CT921CY Series
From 1.0 µH to 150 µH
*IDC
Max.
(A)
3.59
2.93
2.42
1.89
1.66
1.45
1.14
1.04
0.93
0.85
0.77
0.70
0.63
0.58
0.53
0.48
0.44
0.40
0.36
0.31
Not shown at actual size.
PHYSICAL DIMENSIONS
Size
Max.
6.3
0.25
A
Max.
6.2
0.24
B
Max.
3.0
0.12
C
D
2.0±0.2
0.08±0.01
E
0.6±0.2
0.02±0.01
F
4.8±0.2
0.19±0.01
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Testing:
Tested on a HP4285A at 100 KHz , 0.1V
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
mm
inches
PAD LAYOUT
06.05.02
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2003 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
