JANHCA1N4123 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> JANHCA1N4123

JANHCA1N4123: DescriptionZener Diode, 39V V(Z), 5%, Silicon, Unidirectional, DIE-2; CategoryDiscrete semiconductor diode; File Size107KB，2 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric View All

JANHCA1N4123 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANHCA1N4123	-	-	View	Buy Now

JANHCA1N4123 Overview

Zener Diode, 39V V(Z), 5%, Silicon, Unidirectional, DIE-2

JANHCA1N4123 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Microsemi
Parts packaging code	DIE
package instruction	S-XXUC-N2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	METALLURGICALLY BONDED
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	S-XXUC-N2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Package body material	UNSPECIFIED
Package shape	SQUARE
Package form	UNCASED CHIP
polarity	UNIDIRECTIONAL
Certification status	Qualified
Guideline	MIL-19500/435F
Nominal reference voltage	39 V
surface mount	YES
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal location	UNSPECIFIED
Maximum voltage tolerance	5%
Working test current	0.25 mA

Preview

Download Datasheet

View All

• 1N4099-1 THRU 1N4135-1 AVAILABLE IN

JAN, JANTX, JANTXV AND

JANS

PER MIL-PRF-19500/435

• LOW CURRENT OPERATION AT 250

• LOW REVERSE LEAKAGE AND LOW NOISE CHARACTERISTICS

• METALLURGICALLY BONDED

1N4099 thru 1N4135

and

1N4099-1 thru 1N4135-1

MAXIMUM RATINGS

Junction and Storage Temperature: -65°C to +175°C

DC Power Dissipation: 500mW @ +50°C

Power Derating: 4 mW / °C above +50°C

Forward Voltage at 200 mA: 1.1 Volts maximum

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified.

JEDEC

TYPE

NUMBER

NOMINAL

ZENER

VOLTAGE

VZ @ lZT

(Note 1)

VOLTS

1N4099

1N4100

1N4101

1N4102

1N4103

1N4104

1N4105

1N4106

1N4107

1N4108

1N4109

1N4110

1N4111

1N4112

1N4113

1N4114

1N4115

1N4116

1N4117

1N4118

1N4119

1N4120

1N4121

1N4122

1N4123

1N4124

1N4125

1N4126

1N4127

1N4128

1N4129

1N4130

1N4131

1N4132

1N4133

1N4134

1N4135

6.8

7.5

8.2

8.7

9.1

100

ZENER

TEST

CURRENT

IZT

MAXIMUM

ZENER

IMPEDANCE

ZZT

(Note 2)

OHMS

200

100

150

200

250

300

400

500

700

800

1000

1200

1500

MAXIMUM REVERSE

LEAKAGE

CURRENT

lR @ VR

MAXIMUM

NOISE

DENSITY

ND @ lZT

MAXIMUM

ZENER

CURRENT

lZM

9.8

8.9

8.1

7.5

6.7

6.4

6.1

5.6

5.1

4.6

4.4

4.2

3.8

250

1.0

.05

.01

VOLTS

5.17

5.70

6.24

6.61

6.92

7.60

8.44

9.12

9.87

10.65

11.40

12.15

12.92

13.67

14.44

15.20

16.72

18.25

19.00

20.46

21.28

22.80

25.08

27.38

29.65

32.65

35.75

38.76

42.60

45.60

47.10

51.68

57.00

62.32

66.12

69.16

76.00

√

FIGURE 1

DESIGN DATA

CASE:

Hermetically sealed glass

case. DO – 35 outline.

LEAD MATERIAL:

Copper clad steel.

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJEC):

250

C/W maximum at L = .375 inch

THERMAL IMPEDANCE: (Z

OJX): 35

C/W maximum

POLARITY:

Diode to be operated with

the banded (cathode) end positive.

MOUNTING POSITION:

ANY.

NOTE 1

The JEDEC type numbers shown above have a Zener voltage tolerance of + 5% of

the nominal Zener voltage. Vz is measured with the device junction in thermal

equilibrium at an ambient temperature of 25°C + 3°C. A “C” suffix denotes a + 2%

tolerance and a “D” suffix denotes a + 1% tolerance.

Zener impedance is derived by superimposing on lZT, A 60 Hz rms a.c. current

equal to 10% of lZT (25

A a.c.).

NOTE 2

6 LAKE STREET, LAWRENCE, MASSACHUSETTS 01841

PHONE (978) 620-2600

FAX (978) 689-0803

WEBSITE: http://www.microsemi.com
