F-213
FFSD–20–S–10.00–01–N
™
(1,27 mm) .050"
FFSD, FFMD SERIES
•••••••••••••••••••
FFMD–20–T–02.00–01–N–R
TIGER EYE FLAT IDC WIRE CABLES
SPECIFICATIONS
Mates with:
FTS, FTSH, EHF,
SHF, ESHF
™
TYPE
STRIP
NO. PINS
PER ROW
END
OPTION
OVERALL
LENGTH
01
OPTION
OTHER
OPTION
Insulator Material:
PBT
Contact:
BeCu
Plating:
10µ" (0,25 µm) Au over 50µ"
(1,27 µm) Ni on contact area;
Sn over 50µ" (1,27 µm) Ni
on balance
Wire:
30 AWG
Current Rating:
0.5A per contact
Operating Temp Range:
-40°C to +105°C
Lead Size Accepted:
(0,41 mm) .016" SQ
Contact Resistance:
15 mΩ
Insertion Depth:
(2,64 mm) .104" to
(3,17 mm) .125"
Insertion Force:
(Single contact only)
5 oz (1,39 N) avg.
Withdrawal Force:
(Single contact only)
3 oz (0,83 N) avg.
RoHS Compliant:
Yes
Note:
This Series is
non-standard, non-returnable.
FFSD
For complete specifications
see www.samtec.com?FFSD
–05, –08, –10,
–13, –17, –20, –25
(Call for other sizes)
= Assembled Length
Assembled Length
in INCHES (± .130")
2 inches minimum
–“XX.XX”
= Notch
Polarization
(FFSD only)
–N
–S
= Single End
–D
= Double End
–T
= (FFMD only)
Transfer End
Leave blank
for –S and –D
End Options.
For –T End Option
Specify “–N”
(Socket has
notch polarization)
(FFMD only)
Reverse
Daisy
–RW
= Wiring
–D “XX”
= Chain
2"
min.
–R
= Reverse
3
Outside
–O
= Reverse
Strain
–SR
= Relief
(Mates only with
ESHF Series)
“XX”
±
1/8"
01
Requires –DXX
No. of positions x
(1,27) .050 + (8,00) .315
SPECIFICATIONS
Mates with:
FLE*, SFMC*,
Transfer End Option
Mates with:
FTS, FTSH,
EHF, SHF, ESHF
For complete specifications
see www.samtec.com?FFMD
Insulator Material:
Black Glass Filled
Polyester
Terminal:
Phosphor Bronze
Contact:
BeCu (-T)
Plating:
Sn over 50µ" (1,27 µm) Ni
Wire:
30 AWG
Current Rating:
0.5A/contact
Operating Temp Range:
-40°C to +105°C
RoHS Compliant:
Yes
*Note:
Standard FFMD callout
will not mate with FLE, SFMC.
Must use gold plated callouts.
(See drawing on web.)
When mated with a socket,
Wire 1 mates with Pin 2;
Wire 2 mates with Pin 1, etc.
Note:
This Series is
non-standard, non-returnable.
02
4" minimum
Middle
–M
= Reverse
3
Blue or black wire
opposite position #1.
1
2
Requires –DXX
3
Not available with
–O, –M, –R or –DXX
• Strain relief option
FFMD
FFSD
= Socket Strip
(1,90) .075
01
FFMD
= Terminal Strip
01
(1,02)
.040
No. of positions x
(1,27) .050 + (4,19) .165
(3,05)
.120
No. of positions x
(1,27) .050 + (4,19) .165
(3,05)
.120
(5,08)
.200
(5,08)
.200
(1,27)
.050
(0,41) .016 SQ
(3,07)
.121
(1,27)
.050
WWW.SAMTEC.COM
