284066-5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> terminals> 284066-5

284066-5: Description15A, STRIP TERMINAL BLOCK, 2 ROWS, 2 DECKS, ROHS COMPLIANT; CategoryThe connector terminals; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

284066-5 Overview

15A, STRIP TERMINAL BLOCK, 2 ROWS, 2 DECKS, ROHS COMPLIANT

284066-5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	STANDARD: UL 94V-0, POLYAMIDE 66, SHROUDED
Fastening method	SOLDER
Manufacturer's serial number	284066
Installation type	BOARD
Number of layers	2
Rows	2
Number of channels	5
Rated current	15 A
Rated voltage	600 V
safety certificate	UL
Terminal and terminal strip types	STRIP TERMINAL BLOCK
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Terminal Blocks & Strips

Product Feature Selector

> Product Details

284066-5 Product Details

Live Product Chat

Product View

Terminal Block Connectors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

View Mating Products (4)

Product Feature Selector

C ontact Us About This Product

284066-5

T E I nternal N umber: 2 8 4 0 6 6 - 5

Product Highlights:

C onnector

C onnector Type = Header

Shrouded

Housing C olor = Green

Not Side Stackable

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

TERMINAL BLOC K MULTIPLE HEADER ASSEMBLY 180? C LOSED ...

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

Terminal Block Stacking C onnectors

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

C onnector Type

= Header

Shrouded

= Yes

Number of Positions

= 5

Mount Angle

= Vertical

Electrical Characteristics:

C urrent Rating, Max. (Amps.) = 15

Voltage (VAC ) = 600

Body Related Features:

Side Stackable

= No

Number of Rows

= Dual

C enterline (mm [in])

= 10.00 [0.394]

C losed End

= With

Interlock

= Without

Flammability Rating = UL 94V-0

PC B Tail Length (mm [in]) = 3.50 [0.138]

Contact Related Features:

Threaded Flange

= Without

Screw Flange

= Without

C ontact Base Material = Phosphor Bronze

C ontact Mating Area Plating Material = Tin

Housing Related Features:

Housing C olor

= Green

Housing Material = Polyamide 6.6

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Other:

Brand = Buchanan

Additional Information:

Product Line Information
