IMC-0805
Vishay Dale
Inductors
High Frequency, Surface Mount, Molded
FEATURES
•
High self-resonant frequency values
•
High Q values at higher frequencies
•
Molded construction provides superior strength and moisture resistance
•
Wirewound construction
•
Tape and reel packaging for automatic handling, 3000/reel, EIA481
•
Compatible with vapor phase and infrared reflow soldering
•
100 % Lead (Pb)-free and RoHS compliant
RoHS
COMPLIANT
STANDARD ELECTRICAL SPECIFICATIONS
Q
TEST
TYPICAL
FREQ.
L&Q
100 800 1.8
Q
(MHz) MIN. MHz MHz GHz
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
6
6
6
8
8
10
10
12
12
15
15
15
15
15
15
15
15
8
8
10
10
10
10
10
10
10
10
10
10
8
20
18
20
20
22
22
22
23
25
25
25
28
28
28
28
28
28
25
24
25
25
25
25
20
20
18
15
—
—
—
58
60
60
60
65
65
65
70
75
75
75
80
70
70
60
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
90
100
105
100
110
110
105
100
95
80
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
RATED
SELF-
DC
RESONANT DCR
FREQ. MIN. ± 30 % CURRENT
(mA)
(MHz)
(Ohms)
6000
6000
5500
5500
4700
3300
3300
3000
3000
2600
2500
2050
2000
1650
1550
1450
1100
800
600
600
600
500
300
200
150
150
100
100
80
80
0.08
0.08
0.10
0.12
0.13
0.14
0.18
0.18
0.22
0.22
0.26
0.30
0.31
0.35
0.39
0.44
0.48
0.66
0.76
1.13
1.24
1.41
1.50
1.66
1.82
1.97
2.07
2.32
2.60
2.98
540
540
540
540
540
540
535
520
480
465
455
395
390
385
360
340
330
285
275
230
195
170
165
160
150
145
140
130
125
120
DIMENSIONS
in inches [millimeters]
0.078 + 0.012 - 0.008
[2.00 + 0.3 - 0.2]
IND.
(nH)
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
TOL.
± 20 %
± 20 %
± 20 %
± 10 %, ± 20 %
± 10 %, ± 20 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
± 5 %, ± 10 %
0.049 ± 0.012
[1.25 ± 0.3]
0.016 ± 0.008
[0.4 ± 0.2]
0.049 ± 0.012
[1.25 ± 0.3]
0.039 ± 0.004
[1.0 ± 0.1]
NOTE:
Tighter tolerance product may be substituted based on availability.
Recommended Pad Layout
0.043 ± 0.004
[1.1 ± 0.1]
ELECTRICAL SPECIFICATIONS
Core Material:
Non-magnetic.
Inductance Range:
3.9 nH to 1000 nH
Inductance Tolerance:
± 20 % for 3.9 nH
to 8.2 nH
± 10 % for 6.8 nH to 1000 nH
± 5 % for 33 nH to 1000 nH
Temperature Range:
- 40 °C to +105 °C
(no load). - 40 °C to + 85 °C (at full rated
current)
TEST EQUIPMENT
• Inductance and Q measured on
HP4191A
• SRF measured on HP8753B
0.043 ± 0.008
[1.1 ± 0.2]
0.134 ± 0.016
[3.4 ± 0.4]
DESCRIPTION
IMC-0805
MODEL
10 nH
INDUCTANCE
VALUE
±
1 0%
INDUCTANCE
TOLERANCE
ER
PACKAGE
CODE
e3
JEDEC LEAD FREE
STANDARD
GLOBAL PART NUMBER
I
M
C
0
8
SIZE
0
5
E
R
1
0
INDUCTANCE
VALUE
N
K
TOL.
PRODUCT FAMILY
PACKAGE
CODE
Document Number 34040
Revision 17-Jan-06
For technical questions, contact Magnetics@vishay.com
www.vishay.com
39
